Installation - Mechanical
RTAC-SVX01J-EN 47
Table 24. Point weights (lbs) - packaged units - 60 Hz
Size-
tons
Isolator Location
12345678910
Aluminum Coils - Standard Efficiency
140 1402 1450 1383 1430 1361 1408 1333 1379 - -
155 1402 1450 1383 1430 1361 1408 1333 1379 - -
170 1461 1450 1383 1430 1361 1408 1339 1386 - -
185 1657 1673 1734 1638 1564 1584 1510 1530 - -
200 1674 1733 1646 1701 1604 1658 1561 1616 - -
225 1539 1601 1522 1584 1493 1555 1465 1527 1438 1500
250 1521 1571 1503 1554 1472 1522 1443 1494 1413 1473
275 1925 2188 1887 2148 1870 2082 1786 2062 1750 1986
300 1936 2173 1974 2198 1994 2230 2029 2266 2080 2334
350 1907 2144 1977 2213 2065 2301 2163 2399 2300 2536
400 2744 2758 2667 2646 2584 2564 2531 2510 2428 2422
450 2812 2774 2791 2753 2770 2733 2750 2712 2729 2569
500 2776 2719 2787 2744 2812 2768 2836 2792 2860 2817
Aluminum Coils - High Efficiency
140 1402 1450 1383 1430 1361 1408 1339 1387 - -
155 1588 1648 1565 1609 1505 1558 1465 1507 - -
170 1657 1652 1565 1622 1515 1579 1465 1530 - -
185 1419 1523 1405 1510 1381 1496 1358 1466 1335 1400
200 1497 1552 1479 1539 1446 1496 1417 1466 1389 1440
225 1661 1686 1649 1674 1629 1654 1613 1639 1591 1617
250 1661 1686 1649 1674 1629 1654 1613 1639 1591 1617
275 1829 2070 1891 2134 1960 2201 2093 2282 2193 2395
300 2147 2392 2120 2391 2087 2357 2049 2319 2014 2284
350 2647 2629 2535 2517 2452 2434 2512 2380 2294 2300
400 2744 2705 2773 2729 2797 2754 2822 2778 2846 2802
Aluminum Coils - Extra Efficiency
140 1657 1652 1565 1622 1515 1579 1465 1530 - -
155 1419 1523 1405 1510 1381 1496 1358 1466 1335 1400
170 1497 1552 1479 1539 1446 1496 1417 1466 1389 1440
185 1661 1686 1649 1674 1629 1654 1613 1639 1591 1617
200 1661 1686 1649 1674 1629 1654 1613 1639 1591 1617
250 1829 2070 1891 2134 1960 2201 2093 2282 2193 2395
275 2147 2392 2120 2391 2087 2357 2049 2319 2014 2284
300 2647 2629 2535 2517 2452 2434 2512 2380 2294 2300
350 2744 2705 2773 2729 2797 2754 2822 2778 2846 2802
Copper Coils - Standard Efficiency
140 1658 1720 1675 1737 1695 1757 1715 1777 - -
155 1658 1720 1675 1737 1695 1757 1715 1777 - -
170 1658 1720 1675 1737 1695 1757 1715 1776 - -
185 2025 2061 2012 2052 1998 2098 1984 2024 - -
200 2042 2121 2040 2114 2038 2129 2036 2110 - -
225 1868 1954 1865 1945 1861 1951 1859 1949 1857 1947
250 1891 1961 1890 1960 1887 1957 1885 1956 1883 1953
275 2505 2768 2458 2700 2358 2589 2215 2501 2130 2384
300 2550 2787 2548 2786 2547 2784 2545 2782 2543 2798
350 2467 2704 2548 2785 2651 2888 2765 3003 2946 3163
400 3474 3498 3372 3350 3272 3207 3207 3184 3082 3077
450 3599 3602 3465 3468 3332 3199 3199 3202 3066 3069
500 3552 3513 3575 3536 3597 3620 3620 3580 3642 3552
Copper Coils - High Efficiency
140 1658 1720 1675 1737 1695 1757 1715 1777 - -
155 1956 2029 1958 2022 1949 2011 1928 2001 - -
170 1965 2040 1958 2035 1949 2098 1939 2014 - -
185 1788 1914 1792 1916 1796 1951 1800 1924 1804 1928
200 1868 1928 1865 1936 1861 1932 1859 1928 1853 1928
225 2077 2125 2090 2135 2105 2152 2118 2166 2137 2185
250 2077 2125 2090 2135 2105 2152 2118 2166 2137 2185
275 2410 2652 2458 2700 2519 2761 2587 2828 2720 2923
300 2825 3097 2766 3037 2690 2962 2605 2876 2526 2798
350 3377 3357 3241 3221 3139 3074 3074 3054 2948 2946
400 3531 3498 3561 3521 3583 3606 3606 3566 3628 3588
Copper Coils - Extra Efficiency
140 1965 2040 1958 2035 1949 2098 1939 2014 - -
155 1788 1914 1792 1916 1796 1951 1800 1924 1804 1928
170 1868 1928 1865 1936 1861 1932 1859 1928 1853 1928
185 2077 2125 2090 2135 2105 2152 2118 2166 2137 2185
200 2077 2125 2090 2135 2105 2152 2118 2166 2137 2185
250 2410 2652 2458 2700 2519 2761 2587 2828 2720 2923
275 2825 3097 2766 3037 2690 2962 2605 2876 2526 2798
300 3377 3357 3241 3221 3139 3074 3074 3054 2948 2946
350 3531 3498 3561 3521 3583 3606 3606 3566 3628 3588
Table 25. Point weights (lbs) - packaged units - 50 Hz
Size
(tons)
Isolator Location
12345678910
Aluminum Coils - Standard Efficiency
140 1402 1450 1383 1430 1361 1408 1333 1379 - -
155 1461 1457 1444 1435 1414 1411 1389 1386 - -
170 1402 1503 1444 1491 1431 1478 1418 1465 - -
185 1674 1733 1646 1699 1586 1645 1532 1596 - -
200 1688 1742 1662 1716 1621 1675 1580 1634 - -
250 1936 1642 1963 1669 1997 1703 2030 1736 2059 1764
275 2059 2353 1973 2266 1870 2164 1787 2062 1683 1986
300 1936 2104 1890 2198 1994 2196 2029 2266 2080 2334
350 2539 2520 2451 2421 2368 2349 2320 2301 2230 2300
375 2437 2386 2491 2440 2519 2478 2562 2511 2620 2569
400 2744 2758 2667 2646 2584 2564 2531 2510 2428 2422
Aluminum Coils - High Efficiency
120 1402 1450 1383 1430 1361 1408 1339 1387 - -
130 1402 1450 1383 1430 1361 1408 1339 1387 - -
140 1402 1450 1383 1430 1361 1408 1339 1387 - -
155 1657 1648 1617 1622 1585 1579 1541 1537 - -
170 1597 1712 1629 1684 1586 1645 1541 1596 - -
185 1468 1552 1455 1539 1446 1522 1417 1494 1389 1472
200 1521 1571 1503 1554 1472 1522 1443 1494 1414 1473
250 1926 2187 1888 2147 1833 2100 1786 2062 2000 2015
275 1907 2174 1973 2209 2022 2273 2093 2244 2193 2444
300 2147 2417 2120 2391 2087 2357 2049 2319 2014 2284
350 2392 2340 2522 2470 2591 2538 2695 2643 2837 2784
375 2755 2718 2735 2698 2715 2678 2695 2658 2674 2637
400 2744 2705 2773 2729 2797 2754 2822 2778 2846 2802
