Trane R Series Installation, Operation And Maintenance

Location
Standard Efficiency
140 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 - -
155 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 - -
170 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 - -
185 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 - -
200 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 - -
225 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61
250 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61
High Efficiency
140 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 - -
155 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 - -
170 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 - -
185 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61
200 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61 Brown 61
Brown 61
Installation - Mechanical
46 RTAC-SVX01J-EN
Table 22. Isolator selections - packaged units - 50 Hz
Size
(tons)
Location
12345678910
Standard Efficiency
140 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 - -
155 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 - -
170 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 - -
185 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 - -
200 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 - -
250 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64
275 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64
300 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64
350 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64
400 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64
High Efficiency
120 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 - -
130 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 - -
140 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 - -
155 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 - -
170 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 - -
185 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62
200 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62 Red 62
250 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64
275 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64
300 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64
350 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64
400 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64 Gray 64
Table 23. Isolator selections - remote units - 60 Hz
Size
(tons)12345678910

Trane R Series Specifications

General

Brand	Trane
Model	R Series
Category	Chiller
Language	English
