Trane R Series Installation, Operation And Maintenance

Installation - Electrical
RTAC-SVX01J-EN 65
Table 35. Standard efficiency - all ambient options
Unit
Size
Rated
Voltage
1
# Pwr
Conn
2
#
Comp
# Fan
Ckt1/
Ckt2
Fan
kW
Fan
FLA
VFD
Input
Cntrl
VA
3
RLA
4
Ckt1/Ckt2
XLRA
5
Ckt1/Ckt2
YLRA
5
Ckt1/Ckt2
MCA
6
Ckt1/
Ckt2
MOP
7
Ckt1/
Ckt2
140
200/60/3 1 2 8 1.5 6.5 7.3 0.83 270/270 1845/1845 600/600 665 800
200/60/3 2 2 4/4 1.5 6.5 7.3 0.83 270/270 1845/1845 600/600 368/364 600/600
230/60/3 1 2 8 1.5 6.5 7.3 0.83 235/235 1556/1556 506/506 586 800
230/60/3 2 2 4/4 1.5 6.5 7.3 0.83 235/235 1556/1556 506/506 324/321 500/500
380/60/3 1 2 8 1.5 3.5 3.7 0.83 142/142 973/973 316/316 350 450
380/60/3 2 2 4/4 1.5 3.5 3.7 0.83 142/142 973/973 316/316 194/192 300/300
460/60/3 1 2 8 1.5 3 3.7 0.83 118/118 774/774 252/252 293 400
460/60/3 2 2 4/4 1.5 3 3.7 0.83 118/118 774/774 252/252 162/160 250/250
575/60/3 1 2 8 1.5 2.5 3.7 0.83 94/94 631/631 205/205 235 300
575/60/3 2 2 4/4 1.5 2.5 3.7 0.83 94/94 631/631 205/205 130/129 200/200
400/50/3 1 2 8 1.5 2.8 3.7 0.83 138/138 896/896 291/291 337 450
400/50/3 2 2 4/4 1.5 2.8 3.7 0.83 138/138 896/896 291/291 187/185 300/300
155
200/60/3 1 2 9 1.5 6.5 7.3 0.83 320/270 2156/1845 701/600 734 1000
200/60/3 2 2 5/4 1.5 6.5 7.3 0.83 320/270 2156/1845 701/600 437/364 700/600
230/60/3 1 2 9 1.5 6.5 7.3 0.83 278/235 1756/1556 571/506 646 800
230/60/3 2 2 5/4 1.5 6.5 7.3 0.83 278/235 1756/1556 571/506 384/321 600/500
380/60/3 1 2 9 1.5 3.5 3.7 0.83 168/142 1060/973 345/316 386 500
380/60/3 2 2 5/4 1.5 3.5 3.7 0.83 168/142 1060/973 345/316 230/192 350/300
460/60/3 1 2 9 1.5 3 3.7 0.83 139/118 878/774 285/252 322 450
460/60/3 2 2 5/4 1.5 3 3.7 0.83 139/118 878/774 285/252 191/160 300/250
575/60/3 1 2 9 1.5 2.5 3.7 0.83 111/94 705/631 229/205 259 350
575/60/3 2 2 5/4 1.5 2.5 3.7 0.83 111/94 705/631 229/205 154/129 250/200
400/50/3 1 2 9 1.5 2.8 3.7 0.83 168/138 1089/896 354/291 377 500
400/50/3 2 2 5/4 1.5 2.8 3.7 0.83 168/138 1089/896 354/291 227/185 350/300
170
200/60/3 1 2 10 1.5 6.5 7.3 0.83 320/320 2156/2156 701/701 791 1000
200/60/3 2 2 5/5 1.5 6.5 7.3 0.83 320/320 2156/2156 701/701 437/433 700/700
230/60/3 1 2 10 1.5 6.5 7.3 0.83 278/278 1756/1756 571/571 696 800
230/60/3 2 2 5/5 1.5 6.5 7.3 0.83 278/278 1756/1756 571/571 384/381 600/600
380/60/3 1 2 10 1.5 3.5 3.7 0.83 168/168 1060/1060 345/345 416 500
380/60/3 2 2 5/5 1.5 3.5 3.7 0.83 168/168 1060/1060 345/345 230/228 350/350
460/60/3 1 2 10 1.5 3 3.7 0.83 139/139 878/878 285/285 346 450
460/60/3 2 2 5/5 1.5 3 3.7 0.83 139/139 878/878 285/285 191/189 300/300
575/60/3 1 2 10 1.5 2.5 3.7 0.83 111/111 705/705 229/229 279 350
575/60/3 2 2 5/5 1.5 2.5 3.7 0.83 111/111 705/705 229/229 154/152 250/250
400/50/3 1 2 10 1.5 2.8 3.7 0.83 168/168 1089/1089 354/354 410 500
400/50/3 2 2 5/5 1.5 2.8 3.7 0.83 168/168 1089/1089 354/354 227/225 350/350
185
200/60/3 1 2 11 1.5 6.5 7.3 0.83 386/320 2525/2156 821/701 880 1200
200/60/3 2 2 6/5 1.5 6.5 7.3 0.83 386/320 2525/2156 821/701 526/433 800/700
230/60/3 1 2 11 1.5 6.5 7.3 0.83 336/278 2126/1756 691/571 775 1000
230/60/3 2 2 6/5 1.5 6.5 7.3 0.83 336/278 2126/1756 691/571 463/381 700/600
380/60/3 1 2 11 1.5 3.5 3.7 0.83 203/168 1306/1060 424/345 463 600
380/60/3 2 2 6/5 1.5 3.5 3.7 0.83 203/168 1306/1060 424/345 277/228 450/350
460/60/3 1 2 11 1.5 3 3.7 0.83 168/139 1065/878 346/285 385 500
460/60/3 2 2 6/5 1.5 3 3.7 0.83 168/139 1065/878 346/285 230/189 350/300
575/60/3 1 2 11 1.5 2.5 3.7 0.83 134/111 853/705 277/229 310 400
575/60/3 2 2 6/5 1.5 2.5 3.7 0.83 134/111 853/705 277/229 185/152 300/250
400/50/3 1 2 11 1.5 2.8 3.7 0.83 198/168 1089/1089 354/354 450 600
400/50/3 2 2 6/5 1.5 2.8 3.7 0.83 198/168 1089/1089 354/354 267/225 450/350
