Installation - Electrical
66 RTAC-SVX01J-EN
200
200/60/3 1 2 12 1.5 6.5 7.3 0.83 386/386 2525/2525 821/821 952 1200
200/60/3 2 2 6/6 1.5 6.5 7.3 0.83 386/386 2525/2525 821/821 526/522 800/800
230/60/3 1 2 12 1.5 6.5 7.3 0.83 336/336 2126/2126 691/691 839 1000
230/60/3 2 2 6/6 1.5 6.5 7.3 0.83 336/336 2126/2126 691/691 463/460 700/700
380/60/3 1 2 12 1.5 3.5 3.7 0.83 203/203 1306/1306 424/424 501 700
380/60/3 2 2 6/6 1.5 3.5 3.7 0.83 203/203 1306/1306 424/424 277/275 450/450
460/60/3 1 2 12 1.5 3 3.7 0.83 168/168 1065/1065 346/346 417 500
460/60/3 2 2 6/6 1.5 3 3.7 0.83 168/168 1065/1065 346/346 230/229 350/350
575/60/3 1 2 12 1.5 2.5 3.7 0.83 134/134 853/853 277/277 335 450
575/60/3 2 2 6/6 1.5 2.5 3.7 0.83 134/134 853/853 277/277 185/184 300/300
400/50/3 1 2 12 1.5 2.8 3.7 0.83 198/198 1089/1089 354/354 483 600
400/50/3 2 2 6/6 1.5 2.8 3.7 0.83 198/198 1089/1089 354/354 267/265 450/450
225
200/60/3 1 2 13 1.5 6.5 7.3 0.83 459/386 2525/2525 821/821 1050 1200
200/60/3 2 2 7/6 1.5 6.5 7.3 0.83 459/386 2525/2525 821/821 624/522 1000/800
230/60/3 1 2 13 1.5 6.5 7.3 0.83 399/336 2126/2126 691/691 924 1200
230/60/3 2 2 7/6 1.5 6.5 7.3 0.83 399/336 2126/2126 691/691 549/460 800/700
380/60/3 1 2 13 1.5 3.5 3.7 0.83 242/203 1306/1306 424/424 554 700
380/60/3 2 2 7/6 1.5 3.5 3.7 0.83 242/203 1306/1306 424/424 329/275 500/450
460/60/3 1 2 13 1.5 3 3.7 0.83 200/168 1065/1065 346/346 460 600
460/60/3 2 2 7/6 1.5 3 3.7 0.83 200/168 1065/1065 346/346 273/229 450/350
575/60/3 1 2 13 1.5 2.5 3.7 0.83 160/134 853/853 277/277 370 500
575/60/3 2 2 7/6 1.5 2.5 3.7 0.83 160/134 853/853 277/277 220/184 350/300
250
200/60/3 1 2 14 1.5 6.5 7.3 0.83 459/459 2525/2525 821/821 1129 1200
200/60/3 2 2 7/7 1.5 6.5 7.3 0.83 459/459 2525/2525 821/821 624/620 1000/1000
230/60/3 1 2 14 1.5 6.5 7.3 0.83 399/399 2126/2126 691/691 994 1200
230/60/3 2 2 7/7 1.5 6.5 7.3 0.83 399/399 2126/2126 691/691 549/545 800/800
380/60/3 1 2 14 1.5 3.5 3.7 0.83 242/242 1306/1306 424/424 596 800
380/60/3 2 2 7/7 1.5 3.5 3.7 0.83 242/242 1306/1306 424/424 329/327 500/500
460/60/3 1 2 14 1.5 3 3.7 0.83 200/200 1065/1065 346/346 495 600
460/60/3 2 2 7/7 1.5 3 3.7 0.83 200/200 1065/1065 346/346 273/272 450/450
575/60/3 1 2 14 1.5 2.5 3.7 0.83 160/160 853/853 277/277 399 500
575/60/3 2 2 7/7 1.5 2.5 3.7 0.83 160/160 853/853 277/277 220/220 350/350
400/50/3 1 3 14 1.5 2.8 3.7 1.2 138-138/198 896-896/1089 291-291/354 570 700
400/50/3 2 3 8/6 1.5 2.8 3.7 1.2 138-138/198 896-896/1089 291-291/354 337/267 450/450
275
200/60/3 1 n/a
200/60/3 2 3 10/6 1.5 6.5 7.3 1.2 320-320/386
2156-2156/
2525
701-701/821 791/526 1000/800
230/60/3 1 n/a
230/60/3 2 3 10/6 1.5 6.5 7.3 1.2 278-278/336
1756-1756/
2126
571-571/691 696/463 800/700
380/60/3 1 n/a
380/60/3 2 3 10/6 1.5 3.5 3.7 1.2 168-168/203
1060-1060/
1306
345-345/424 417/277 500/450
460/60/3 1 3 16 1.5 3 3.7 1.2 139-139/168 878-878/1065 285-285/346 542 700
460/60/3 2 3 10/6 1.5 3 3.7 1.2 139-139/168 878-878/1065 285-285/346 346/231 450/350
575/60/3 1 3 16 1.5 2.5 3.7 1.2 111-111/134 705-705/853 229-229/277 436 500
575/60/3 2 3 10/6 1.5 2.5 3.7 1.2 111-111/134 705-705/853 229-229/277 279/185 350/300
400/50/3 1 3 16 1.5 2.8 3.7 1.2 168-168/198
1089-1089/
1089
354-354/354 635 800
400/50/3 2 3 10/6 1.5 2.8 3.7 1.2 168-168/198
1089-1089/
1089
354-354/354 410/267 500/450
Table 35. Standard efficiency - all ambient options (continued)
Unit
Size
Rated
Voltage
1
# Pwr
Conn
2
#
Comp
# Fan
Ckt1/
Ckt2
Fan
kW
Fan
FLA
VFD
Input
Cntrl
VA
3
RLA
4
Ckt1/Ckt2
XLRA
5
Ckt1/Ckt2
YLRA
5
Ckt1/Ckt2
MCA
6
Ckt1/
Ckt2
MOP
7
Ckt1/
Ckt2
