Installation - Electrical
RTAC-SVX01J-EN 67
300
200/60/3 1 n/a
200/60/3 2 3 12/6 1.5 6.5 7.3 1.2 386-386/386
2525-2525/
2525
821-821/821 925/526 1200/800
230/60/3 1 n/a
230/60/3 2 3 12/6 1.5 6.5 7.3 1.2 336-336/336
2126-2126/
2126
691-691/691 839/463 1000/700
380/60/3 1 n/a
380/60/3 2 3 12/6 1.5 3.5 3.7 1.2 203-203/203
1306-1306/
1306
424-424/424 501/277 700/450
460/60/3 1 3 18 1.5 3 3.7 1.2 168-168/168
1065-1065/
1065
346-346/346 606 700
460/60/3 2 3 12/6 1.5 3 3.7 1.2 168-168/168
1065-1065/
1065
346-346/346 417/231 500/350
575/60/3 1 3 18 1.5 2.5 3.7 1.2 134-134/134 853-853/853 277-277/277 487 600
575/60/3 2 3 12/6 1.5 2.5 3.7 1.2 134-134/134 853-853/853 277-277/277 335/185 450/300
400/50/3 1 3 18 1.5 2.8 3.7 1.2 198-198/198
1089-1089/
1089
354-354/354 701 800
400/50/3 2 3 12/6 1.5 2.8 3.7 1.2 198-198/198
1089-1089/
1089
354-354/354 483/267 600/450
350
200/60/3 1 n/a
200/60/3 2 3 14/6 1.5 6.5 7.3 1.2 459-459/386
2525-2525/
2525
821-821/821 1130/526 1200/800
230/60/3 1 n/a
230/60/3 2 3 14/6 1.5 6.5 7.3 1.2 399-399/336
2126-2126/
2126
691-691/691 994/463 1200/700
380/60/3 1 n/a
380/60/3 2 3 14/6 1.5 3.5 3.7 1.2 242-242/203
1306-1306/
1306
424-424/424 596/277 800/450
460/60/3 1 3 20 1.5 3 3.7 1.2 200-200/168
1065-1065/
1065
346-346/346 684 800
460/60/3 2 3 14/6 1.5 3 3.7 1.2 200-200/168
1065-1065/
1065
346-346/346 495/231 600/350
575/60/3 1 3 20 1.5 2.5 3.7 1.2 160-160/134 853-853/853 277-277/277 551 700
575/60/3 2 3 14/6 1.5 2.5 3.7 1.2 160-160/134 853-853/853 277-277/277 399/185 500/300
400/50/3 1 4 20 1.5 2.8 3.7 1.59
168-168/168-
168
1089-1089/
1089-1089
354-354/
354-354
778 800
400/50/3 2 4 10/10 1.5 2.8 3.7 1.59
168-168/168-
168
1089-1089/
1089-1089
354-354/
354-354
410/410 500/500
375
400/50/3 1 4 22 1.5 2.8 3.7 1.59
198-198/168-
168
1089-1089/
1089-1089
354-354/
354-354
851 1000
400/50/3 2 4 12/10 1.5 2.8 3.7 1.59
198-198/168-
168
1089-1089/
1089-1089
354-354/
354-354
483/410 600/500
Table 35. Standard efficiency - all ambient options (continued)
Unit
Size
Rated
Voltage
1
# Pwr
Conn
2
#
Comp
# Fan
Ckt1/
Ckt2
Fan
kW
Fan
FLA
VFD
Input
Cntrl
VA
3
RLA
4
Ckt1/Ckt2
XLRA
5
Ckt1/Ckt2
YLRA
5
Ckt1/Ckt2
MCA
6
Ckt1/
Ckt2
MOP
7
Ckt1/
Ckt2
