Trane R Series Installation, Operation And Maintenance

Installation - Electrical
RTAC-SVX01J-EN 99
Analog Input, 25 Local Atmospheric Pressure Local atmospheric pressure. PSI
Analog Input, 26 Starts- Compressor 1A Number of starts for compressor 1A. None
Analog Input, 27 Starts- Compressor 1B Number of starts for compressor 1B. None
Analog Input, 28 Starts- Compressor 2A Number of starts for compressor 2A. None
Analog Input, 29 Starts- Compressor 2B Number of starts for compressor 2B. None
Analog Input, 34 Run Time- Compressor 1A Total run time of compressor 1A. Hours
Analog Input, 35 Run Time- Compressor 1B Total run time of compressor 1B. Hours
Analog Input, 36 Run Time- Compressor 2A Total run time of compressor 2A. Hours
Analog Input, 37 Run Time- Compressor 2B Total run time of compressor 2B. Hours
Analog Input, 42 Airflow Percentage- Circuit 1 Approximate airflow percentage of circuit 1. Percent (98)
Analog Input, 43 Airflow Percentage- Circuit 2 Approximate airflow percentage of circuit 2. Percent (98)
Analog Input, 44 Evaporator Entering Water Temp Temperature of the water entering the evaporator. Degrees-Fahrenheit (64)
Analog Input, 45 Evaporator Leaving Water Temp Temperature of the water leaving the evaporator. Degrees-Fahrenheit (64)
Analog Input, 46 Condenser Entering Water Temp Temperature of the water entering the condenser. Degrees-Fahrenheit (64)
Analog Input, 47 Condenser Leaving Water Temp Temperature of the water leaving the condenser. Degrees-Fahrenheit (64)
Analog Input, 48 High Side Oil Pressure- Compressor 1A
Pressure of the oil at the high side of compressor
1A.
PSI
Analog Input, 49 High Side Oil Pressure- Compressor 1B Pressure of oil at high side of compressor 1B. PSI
Analog Input, 50 High Side Oil Pressure- Compressor 2A Pressure of oil at high side of compressor 2A. PSI
Analog Input, 51 High Side Oil Pressure- Compressor 2B Pressure of oil at high side of compressor 2B. PSI
Analog Input, 56 Refrigerant Disch Temp- Ckt 1
Temperature of refrigerant being discharged from
Ckt 1.
Degrees-Fahrenheit (64)
Analog Input, 57 Outdoor Air Temperature Outdoor air temperature. Degrees-Fahrenheit (64)
Analog Input, 58 Condenser Control Output
Percentage of condenser water flow being
requested by the chiller.
Percent (98)
Analog Input, 59 Phase AB Voltage- Compressor 1A Phase AB voltage, compressor 1A. Volts
Analo5 Input, 62 Phase AB Voltage- Compressor 1B Phase AB voltage, compressor 1B. Volts
Analog Input, 65 Phase AB Voltage- Compressor 2A Phase AB voltage, compressor 2A. Volts
Analog Input, 68 Phase AB Voltage- Compressor 2B Phase AB voltage, compressor 2B. Volts
Analog Input, 71 Line 1 Current (in Amps)- Compressor 1A Line 1 Current (in Amps)- Compressor 1A Amps
Analog Input, 72 Line 2 Current (in Amps)- Compressor 1A Line 2 Current (in Amps)- Compressor 1A Amps
Analog Input, 73 Line 3 Current (in Amps)- Compressor 1A Line 3 Current (in Amps)- Compressor 1A Amps
Analog Input, 74 Line 1 Current (in Amps)- Compressor 1B Line 1 Current (in Amps)- Compressor 1B Amps
Analog Input, 75 Line 2 Current (in Amps)- Compressor 1B Line 2 Current (in Amps)- Compressor 1B Amps
Analog Input, 76 Line 3 Current (in Amps)- Compressor 1B Line 3 Current (in Amps)- Compressor 1B Amps
Analog Input, 77 Line 1 Current (in Amps)- Compressor 2A Line 1 Current (in Amps)- Compressor 2A Amps
Analog Input, 78 Line 2 Current (in Amps)- Compressor 2A Line 2 Current (in Amps)- Compressor 2A Amps
Analog Input, 79 Line 3 Current (in Amps)- Compressor 2A Line 3 Current (in Amps)- Compressor 2A Amps
Analog Input, 80 Line 1 Current (in Amps)- Compressor 2B Line 1 Current (in Amps)- Compressor 2B Amps
Analog Input, 81 Line 2 Current (in Amps)- Compressor 2B Line 2 Current (in Amps)- Compressor 2B Amps
Analog Input, 82 Line 3 Current (in Amps)- Compressor 2B Line 3 Current (in Amps)- Compressor 2B Amps
Analog Input, 83 Line 1 Current (%RLA)- Compressor 1A Line 1 Current (%RLA)- Compressor 1A Percent (98)
Analog Input, 84 Line 2 Current (%RLA)- Compressor 1A Line 2 Current (%RLA)- Compressor 1A Percent (98
Analog Input, 85 Line 3 Current (%RLA)- Compressor 1A Line 3 Current (%RLA)- Compressor 1A Percent (98)
Analog Input, 86 Line 1 Current (%RLA)- Compressor 1B Line 1 Current (%RLA)- Compressor 1B Percent (98)
Analog Input, 87 Line 2 Current (%RLA)- Compressor 1B Line 2 Current (%RLA)- Compressor 1B Percent (98)
Analog Input, 88 Line 3 Current (%RLA)- Compressor 1B Line 3 Current (%RLA)- Compressor 1B Percent (98)
Table 48. Analog Input (continued)
Object
Identifier
Object Name Description Units
