Installation - Electrical
100 RTAC-SVX01J-EN
Analog Input, 89 Line 1 Current (%RLA)- Compressor 2A Line 1 Current (%RLA)- Compressor 2A Percent (98)
Analog Input, 90 Line 2 Current (%RLA)- Compressor 2A Line 2 Current (%RLA)- Compressor 2A Percent (98)
Analog Input, 91 Line 3 Current (%RLA)- Compressor 2A Line 3 Current (%RLA)- Compressor 2A
Percent (98)
Analog Input, 92 Line 1 Current (%RLA)- Compressor 2B Line 1 Current (%RLA)- Compressor 2B Percent (98
Analog Input, 93 Line 2 Current (%RLA)- Compressor 2B Line 2 Current (%RLA)- Compressor 2B
Percent (98)
Analog Input, 94 Line 3 Current (%RLA)- Compressor 2B Line 3 Current (%RLA)- Compressor 2B Percent (98)
Analog Input, 95 Number of Circuits Number of Circuits
None
Analog Input, 96 Number of Compressors, Ckt 1 Number of Compressors, Ckt 1 None
Analog Input, 97 Number of Compressors, Ckt 2 Number of Compressors, Ckt 2 None
Table 49. Multistate Output
Object Identifier Object Name Description
Relinq
Default
Object States
Multi-State Output, 1 Chiller Mode Command Mode of operation of the chiller. 1 = Cool
1 = HVAC _Heat
2 = HVAC_Cool
3 = HVAC_Ice
4 = Not Used
Table 50. Multistate Input
BCI-C Object
Identifier
Object Name Description Object States
Multi-State Input, 1 Running Mode Indicates the primary running mode of the chiller.
1 = Chiller Off
2 = Chiller in Start Mode
3 = Chiller in Run Mode
4 = Chiller in Pre-shutdown Mode
5 = Chiller in Service Mode
Multi-State Input, 2 Operating Mode Indicates the primary operating mode of the chiller.
1 = HVAC_Heat
2 = HVAC_Cool
3 = HVAC_Ice
4 = Not Used
Multi-State Input, 3
MP Communication
Status
Communication status.
1 = R-22
2 = Communication
3 = Communication Lost
4 = Failed to Established
5 = Waiting to Establish
Multi-State Input, 4 Refrigerant Type Refrigerant type.
1 = R-11
2 = R-12
3 = R-22
4 = R-123
5 = R-134A
6 = R407C
7 = R-410A
Table 48. Analog Input (continued)
Object
Identifier
Object Name Description Units
