Trane RTAF SE Series User Manual

RLC-SVX19A-E4
38
General Electrical Recommendations
Table 17 – Fan Motor and Control Circuit Data - Standard Effi ciency
Fan (Each) Control Evaporator
Unit Size Qty kW (1)/kW (2) FLA (2) kW A
Heater
kW
Standard noise level/Low noise level
090 8 1.94/2.56 3.9 1.776 4.41 0.8
105 8 1.94/2.56 3.9 1.776 4.41 0.8
125 8 1.94/2.56 3.9 1.776 4.41 0.8
145 10 1.94/2.56 3.9 1.776 4.41 0.8
155 10 1.94/2.56 3.9 1.776 4.41 0.8
175 10 1.94/2.56 3.9 1.776 4.41 1.2
190 12 1.94/2.56 3.9 1.776 4.41 1.2
205 12 1.94/2.56 3.9 1.776 4.41 1.2
Extra low noise level
090 8 2.56/2.56 3.9 1.776 4.41 0.8
105 8 2.56/2.56 3.9 1.776 4.41 0.8
125 8 2.56/2.56 3.9 1.776 4.41 0.8
145 10 2.56/2.56 3.9 1.776 4.41 0.8
155 10 2.56/2.56 3.9 1.776 4.41 0.8
175 10 2.56/2.56 3.9 1.776 4.41 1.2
190 12 2.56/2.56 3.9 1.776 4.41 1.2
205 12 2.56/2.56 3.9 1.776 4.41 1.2
Notes:
1. Max power input per fan for standard and high ambient
2. Max power input per fan for low ambient
3. Maximum FLA per fan for standard and high ambient and low ambient
4. Compressor maximum amps under 400/3/50Hz
5. Compressor start up amps under 400/3/50Hz
Table 18 – Fan Motor and Control Circuit Data - High Effi ciency
Fan (Each) Control Evaporator
Unit Size Qty kW (1)/kW (2) FLA (3) kW A
Heater
kW
Standard noise level/Low noise level
090 10 1.94/- 3.9 1.776 4.41 0.8
105 10 1.94/- 3.9 1.776 4.41 0.8
125 10 1.94/- 3.9 1.776 4.41 0.8
145 12 1.94/- 3.9 1.776 4.41 0.8
155 12 1.94/- 3.9 1.776 4.41 0.8
175 12 1.94/- 3.9 1.776 4.41 1.2
190 14 1.94/- 3.9 1.776 4.41 1.2
205 14 1.94/- 3.9 1.776 4.41 1.2
Notes:
1. Max power input per Fan for standard & high ambient
2. Low ambient NOT AVAILABLE with high effi ciency unit
3. Maximum FLA per Fan for standard & high ambient
4. Compressor maximum Amps under 400/3/50Hz
5. Compressor Start up Amps under 400/3/50Hz
