Trane RTAF SE Series User Manual

RLC-SVX19A-E4
39
General Electrical Recommendations
Table 19 – Fan Motor and Control circuit data - Extra Effi ciency
Fan (Each) Control Evaporator
Unit Size Qty kW (1)/kW (2) FLA (3) kW A
Heater
kW
Standard noise level/Low noise level
090 10 2.56/2.56 3.9 1.776 4.41 0.8
105 10 2.56/2.56 3.9 1.776 4.41 0.8
125 10 2.56/2.56 3.9 1.776 4.41 0.8
145 12 2.56/2.56 3.9 1.776 4.41 0.8
155 12 2.56/2.56 3.9 1.776 4.41 0.8
175 12 2.56/2.56 3.9 1.776 4.41 1.2
190 14 2.56/2.56 3.9 1.776 4.41 1.2
205 14 2.56/2.56 3.9 1.776 4.41 1.2
Extra low noise level
090 10 2.56/2.56 3.9 1.776 4.41 0.8
105 10 2.56/2.56 3.9 1.776 4.41 0.8
125 10 2.56/2.56 3.9 1.776 4.41 0.8
145 12 2.56/2.56 3.9 1.776 4.41 0.8
155 12 2.56/2.56 3.9 1.776 4.41 0.8
175 12 2.56/2.56 3.9 1.776 4.41 1.2
190 14 2.56/2.56 3.9 1.776 4.41 1.2
205 14 2.56/2.56 3.9 1.776 4.41 1.2
Notes:
1. Max power input per Fan for standard & high ambient
2. Max power input per Fan for low ambient
3. Maximum FLA per Fan for standard & high ambient and low ambient
4. Compressor maximum Amps under 400/3/50Hz
5. Compressor Start up Amps under 400/3/50Hz
Table 20 – Fan Motor and Control circuit data - High Seasonal Effi ciency
Fan (Each) Control Evaporator
Unit Size Qty kW (1)/kW (2) FLA (3) kW A
Heater
kW
Standard noise level/Low noise level
090 10 2.56/2.56 3.9 1.776 4.41 0.8
105 10 2.56/2.56 3.9 1.776 4.41 0.8
125 10 2.56/2.56 3.9 1.776 4.41 0.8
145 12 2.56/2.56 3.9 1.776 4.41 0.8
155 12 2.56/2.56 3.9 1.776 4.41 0.8
175 12 2.56/2.56 3.9 1.776 4.41 1.2
190 14 2.56/2.56 3.9 1.776 4.41 1.2
205 14 2.56/2.56 3.9 1.776 4.41 1.2
Extra low noise level
090 10 2.56/2.56 3.9 1.776 4.41 0.8
105 10 2.56/2.56 3.9 1.776 4.41 0.8
125 10 2.56/2.56 3.9 1.776 4.41 0.8
145 12 2.56/2.56 3.9 1.776 4.41 0.8
155 12 2.56/2.56 3.9 1.776 4.41 0.8
175 12 2.56/2.56 3.9 1.776 4.41 1.2
190 14 2.56/2.56 3.9 1.776 4.41 1.2
205 14 2.56/2.56 3.9 1.776 4.41 1.2
Notes:
1. Max power input per Fan for standard & high ambient
2. Max power input per Fan for low ambient
3. Maximum FLA per Fan for standard & high ambient and low ambient
4. Compressor maximum Amps under 400/3/50Hz
5. Compressor Start up Amps under 400/3/50Hz
