Trane RTAF SE Series User Manual

RLC-SVX19A-E4
40
General Electrical Recommendations
Table 21 – Electrical data
Compressor Data Control Circuit Data
RTAF
Quantity
Maximum Amps (4) Starting Amps (5)
Disconnect switch Option
Power Cable Cross section
Size Cmpr 1 Cmpr 2 Cmpr 1 Cmpr 2 Min (mm²) Max (mm²)
Standard Effi ciency
90 2 97 97 144 144 185 240
105 2 116 116 180 180 185 240
125 2 158 116 259 180 240 240
145 2 158 158 259 259 2x150 2x300
155 2 197 158 291 259 2x150 2x300
175 2 234 158 354 259 2x185 2x300
190 2 234 197 354 291 2x185 2x300
205 2 234 234 354 354 2x185 2x300
High Effi ciency
90 2 97 97 144 144 185 240
105 2 116 116 180 180 185 240
125 2 158 116 259 180 240 240
145 2 158 158 259 259 2x150 2x300
155 2 197 158 291 259 2x150 2x300
175 2 234 158 354 259 2x185 2x300
190 2 234 197 354 291 2x185 2x300
205 2 234 234 354 354 2x185 2x300
Notes:
1. Max power input per Fan for standard & high ambient
2. Max power input per Fan for low ambient
3. Maximum FLA per Fan for standard & high ambient and low ambient
4. Compressor maximum Amps under 400/3/50Hz
5. Compressor Start up Amps under 400/3/50Hz
Table 22 – Electrical data
Compressor Data Control Circuit Data
RTAF
Quantity
Maximum Amps (4) Starting Amps (5)
Disconnect switch Option
Power Cable Cross section
Size Cmpr 1 Cmpr 2 Cmpr 1 Cmpr 2 Min (mm²) Max (mm²)
Extra Effi ciency
90 2 97 97 144 144 185 240
105 2 116 116 180 180 185 240
125 2 158 116 259 180 240 240
145 2 158 158 259 259 2x150 2x300
155 2 197 158 291 259 2x150 2x300
175 2 234 158 354 259 2x185 2x300
190 2 234 197 354 291 2x185 2x300
205 2 234 234 354 354 2x185 2x300
High Seasonal Effi ciency
90 2 90 90 90 90 185 240
105 2 105 105 105 105 185 240
125 2 147 105 147 105 240 240
145 2 147 147 147 147 2x150 2x300
155 2 182 147 182 147 2x150 2x300
175 2 206 147 206 147 2x185 2x300
190 2 206 182 206 182 2x185 2x300
205 2 206 206 206 206 2x185 2x300
Notes:
1. Max power input per Fan for standard & high ambient
2. Max power input per Fan for low ambient
3. Maximum FLA per Fan for standard & high ambient and low ambient
4. Compressor maximum Amps under 400/3/50Hz
5. Compressor Start up Amps under 400/3/50Hz
