Trane S9V2B040U3PSBC/D User Manual

18
S9V2-SVX001-1A-EN
Table 6. S9V2B040D3PSBC/D Heating Airflow
S9V2B040D3PSBC/D Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure
with Filter (iwc)
1st Stage Capacity = 25,300
2nd Stage Capacity = 38,850
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 468
CFM 464 453 442 431 420
Temp. Rise
51 52 53 54 55
Watts 26 55 84 113 142
Medium Low
(a)
634
CFM 616 607 599 591 583
Temp. Rise
38 38 39 40 40
Watts 40 78 115 152 190
Medium 684
CFM 635 643 650 658 666
Temp. Rise
37 37 36 36 35
Watts 47 106 165 224 283
High
900
CFM 824 843 861 880 898
Temp. Rise
28 28 27 26 26
Watts 82 130 178 226 274
Heating 2nd
Stage
Low 650
CFM 662 655 649 642 635
Temp. Rise
54 55 55 56 56
Watts 37 79 120 162 203
Medium Low
(a)
880
CFM 811 818 826 834 841
Temp. Rise
45 44 44 43 42
Watts 67 121 176 230 284
Medium 950
CFM 859 865 871 877 884
Temp. Rise
42 41 41 41 41
Watts 88 144 200 256 312
High
1250
CFM 1082 1092 1102 1111 1121
Temp. Rise
33 33 33 33 33
Watts 192 253 314 375 436
(a)
Factory Setting.
Table 7. S9V2B040U3PSBC/D / S9V2B040D3PSBC/D Cooling Airflow
S9V2B040U3PSBC/D / S9V2B040D3PSBC/D Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static
Pressure with Filter (iwc)
Cooling
Unit
Outdoor
Airflow
Setting
(CFM/ton)
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Cooling
1.5 Ton
Cooling 450
CFM/Ton
CFM 675 675 675 675 675
Watts 47 81 121 166 215
Cooling 420
CFM/Ton
CFM 630 630 630 630 630
Watts 40 72 111 154 202
Cooling 400
CFM/Ton
CFM 600 600 600 600 600
Watts 36 67 105 147 193
Cooling 370
CFM/Ton
CFM 555 555 555 555 555
Watts 30 60 96 136 181
Cooling 350
CFM/Ton
CFM 525 525 525 525 525
Watts 27 56 90 130 174
Cooling 330
CFM/Ton
CFM 495 495 495 495 495
Watts 24 51 85 124 167
Cooling 310
CFM/Ton
CFM 465 465 465 465 465
Watts 21 48 80 118 161
Cooling 290
CFM/Ton
CFM 435 435 435 435 435
Watts 19 44 76 113 155
Cooling
2.0 Ton
Cooling 450
CFM/Ton
CFM 900 900 900 900 900
Watts 94 137 186 240 298
Cooling 420
CFM/Ton
CFM 840 840 840 840 840
Watts 79 120 166 218 273
Cooling 400
CFM/Ton
CFM 800 800 800 800 800
Watts 70 109 154 204 258
Cooling 370
CFM/Ton
CFM 740 740 740 740 740
Watts 58 95 138 185 236
Cooling 350
CFM/Ton
CFM 700 700 700 700 700
Watts 51 86 127 173 223
Cooling 330
CFM/Ton
CFM 660 660 660 660 660
Watts 44 78 118 162 211
Cooling 310
CFM/Ton
CFM 620 620 620 620 620
Watts 38 71 109 152 199
Cooling 290
CFM/Ton
CFM 580 580 580 580 580
Watts 33 64 101 142 188
HHeeaattiinngg aanndd CCoooolliinngg AAiirrffllooww TTaabblleess
