Trane S9V2B040U3PSBC/D User Manual

S9V2-SVX001-1A-EN
21
Table 10. S9V2B060U4PSBC/D Heating Airflow
S9V2B060U4PSBC/D Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure
with Filter (iwc)
1st Stage Capacity = 38,100
2nd Stage Capacity = 58,400
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 782
CFM 776 769 762 756 749
Temp. Rise
45 45 45 45 46
Watts 70 109 149 188 227
Medium Low 861
CFM 842 823 805 786 768
Temp. Rise
42 43 43 44 44
Watts 88 126 164 202 240
Medium
(a)
916
CFM 863 860 858 855 853
Temp. Rise
41 41 41 41 41
Watts 105 143 181 219 257
High
1027
CFM 1105 1084 1063 1042 1021
Temp. Rise
32 32 33 34 34
Watts 135 173 210 248 285
Heating 2nd
Stage
Low 990
CFM 1002 996 990 984 979
Temp. Rise
55 55 55 55 55
Watts 126 172 219 266 313
Medium Low 1090
CFM 1130 1117 1105 1092 1079
Temp. Rise
49 49 49 50 50
Watts 160 206 253 300 347
Medium
(a)
1160
CFM 1139 1133 1128 1122 1116
Temp. Rise
48 48 49 49 49
Watts 181 231 281 331 381
High
1300
CFM 1319 1307 1295 1283 1272
Temp. Rise
41 42 42 42 43
Watts 246 300 353 407 461
(a)
Factory Setting.
Table 11. S9V2B060U4PSBC/D Cooling Airflow
S9V2B060U4PSBC/D Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter (iwc)
Cooling
Unit
Outdoor
Airflow
Setting
(CFM/ton)
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Cooling
1.5 Ton
Cooling 450
CFM/Ton
CFM 663 673 666 641 596
Watts 47 83 119 155 192
Cooling 420
CFM/Ton
CFM 621 630 621 595 549
Watts 41 75 109 144 180
Cooling 400
CFM/Ton
CFM 582 580 566 528 507
Watts 36 67 99 130 170
Cooling 370
CFM/Ton
CFM 549 556 546 517 469
Watts 32 63 95 128 162
Cooling 350
CFM/Ton
CFM 521 527 516 486 437
Watts 29 59 90 122 156
Cooling 330
CFM/Ton
CFM 492 497 486 455 405
Watts 26 55 85 117 150
Cooling 310
CFM/Ton
CFM 463 468 455 423 372
Watts 23 51 81 112 145
Cooling 290
CFM/Ton
CFM 435 438 424 391 339
Watts 21 48 77 107 141
Cooling
2.0 Ton
Cooling 450
CFM/Ton
CFM 878 893 890 869 829
Watts 90 135 179 223 266
Cooling 420
CFM/Ton
CFM 821 834 830 808 767
Watts 76 119 161 202 244
Cooling 400
CFM/Ton
CFM 770 778 770 742 725
Watts 66 105 144 182 230
Cooling 370
CFM/Ton
CFM 725 737 731 707 664
Watts 57 96 134 172 211
Cooling 350
CFM/Ton
CFM 687 698 691 666 622
Watts 51 88 124 161 199
Cooling 330
CFM/Ton
CFM 649 659 651 625 580
Watts 45 80 115 151 188
Cooling 310
CFM/Ton
CFM 611 620 611 584 538
Watts 39 73 107 142 177
Cooling 290
CFM/Ton
CFM 573 581 571 543 496
Watts 34 67 99 133 168
HHeeaattiinngg aanndd CCoooolliinngg AAiirrffllooww TTaabblleess
