Table 11. S9V2B060U4PSBC/D Cooling Airflow (continued)
S9V2B060U4PSBC/D Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter (iwc)
Cooling
Unit
Outdoor
Airflow
Setting
(CFM/ton)
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Cooling
2.5 Ton
Cooling 450
CFM/Ton
CFM 1097 1114 1114 1097 1061
Watts 159 212 265 317 368
Cooling 420
CFM/Ton
CFM 1023 1040 1039 1020 984
Watts 133 184 233 282 331
Cooling 400
CFM/Ton
CFM 976 989 990 970 932
Watts 117 166 214 261 308
Cooling 370
CFM/Ton
CFM 902 917 915 894 855
Watts 97 142 187 232 276
Cooling 350
CFM/Ton
CFM 854 868 865 843 803
Watts 84 128 171 214 257
Cooling 330
CFM/Ton
CFM 806 819 815 793 752
Watts 73 115 157 198 239
Cooling 310
CFM/Ton
CFM 759 771 766 742 700
Watts 63 103 143 182 222
Cooling 290
CFM/Ton
CFM 711 722 716 692 648
Watts 55 93 130 168 206
Cooling
3.0 Ton
Cooling 450
CFM/Ton
CFM 1319 1340 1343 1328 1295
Watts 260 321 382 441 501
Cooling 420
CFM/Ton
CFM 1229 1249 1251 1235 1201
Watts 215 274 331 387 443
Cooling 400
CFM/Ton
CFM 1170 1189 1190 1173 1139
Watts 189 245 300 354 408
Cooling 370
CFM/Ton
CFM 1082 1100 1099 1081 1046
Watts 154 206 258 309 360
Cooling 350
CFM/Ton
CFM 1023 1040 1039 1020 984
Watts 133 184 233 282 331
Cooling 330
CFM/Ton
CFM 965 981 979 960 922
Watts 114 163 210 257 304
Cooling 310
CFM/Ton
CFM 907 922 919 899 860
Watts 98 144 189 234 278
Cooling 290
CFM/Ton
CFM 850 863 860 838 798
Watts 83 127 170 212 255
Cooling
3.5 Ton
Cooling 450
CFM/Ton
CFM 1546 1570 1576 1564 1534
Watts 399 469 537 604 671
Cooling 420
CFM/Ton
CFM 1440 1462 1466 1453 1422
Watts 329 395 459 523 586
Cooling 400
CFM/Ton
CFM 1369 1391 1394 1380 1348
Watts 287 350 413 474 535
Cooling 370
CFM/Ton
CFM 1264 1284 1287 1271 1238
Watts 232 291 350 408 465
Cooling 350
CFM/Ton
CFM 1195 1214 1215 1199 1165
Watts 199 257 313 368 423
Cooling 330
CFM/Ton
CFM 1126 1144 1145 1127 1092
Watts 170 225 278 331 384
Cooling 310
CFM/Ton
CFM 1059 1075 1074 1056 1020
Watts 145 197 248 298 348
Cooling 290
CFM/Ton
CFM 992 1006 1004 985 948
Watts 122 171 219 267 315
Cooling
4.0 Ton
(a)
Cooling 450
CFM/Ton
CFM 1779 1806 1814 1805 1778
Watts 585 661 737 812 886
Cooling 420
CFM/Ton
CFM 1654 1679 1686 1676 1647
Watts 480 552 624 695 765
Cooling 400
CFM/Ton
CFM 1572 1596 1602 1590 1561
Watts 418 488 557 625 693
Cooling 370
CFM/Ton
CFM 1450 1472 1477 1464 1433
Watts 335 401 466 530 594
Cooling 350
CFM/Ton
(a)
CFM 1369 1391 1394 1380 1348
Watts 287 350 413 474 535
Cooling 330
CFM/Ton
CFM 1289 1310 1312 1297 1264
Watts 244 305 364 423 481
Cooling 310
CFM/Ton
CFM 1210 1229 1231 1214 1180
Watts 206 264 320 376 431
Cooling 290
CFM/Ton
CFM 1131 1149 1150 1132 1097
Watts 172 227 281 334 386
(a)
Factory Setting.
