Trane S9V2B040U3PSBC/D User Manual

S9V2-SVX001-1A-EN
23
Table 12. S9V2B080U4PSBC/D Heating Airflow
S9V2B080U4PSBC/D Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure
with Filter (iwc)
1st Stage Capacity = 50,500
2nd Stage Capacity = 77,700
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 864
CFM 914 882 849 816 783
Temp. Rise
51 53 55 57 59
Watts 90 131 172 213 255
Medium Low
(a)
907
CFM 940 912 885 858 831
Temp. Rise
50 51 53 54 56
Watts 104 141 178 215 253
Medium 958
CFM 983 932 881 830 779
Temp. Rise
47 50 53 55 58
Watts 118 151 184 218 251
High
1051
CFM 1029 1068 1107 1146 1185
Temp. Rise
45 44 42 40 39
Watts 155 195 235 275 314
Heating 2nd
Stage
Low 1200
CFM 1207 1206 1205 1204 1203
Temp. Rise
60 60 60 60 60
Watts 206 258 309 361 412
Medium Low
(a)
1260
CFM 1260 1261 1262 1263 1264
Temp. Rise
57 57 57 57 57
Watts 232 287 342 397 452
Medium 1330
CFM 1360 1347 1333 1320 1306
Temp. Rise
53 53 54 54 55
Watts 263 322 380 439 497
High
1460
CFM 1420 1439 1458 1477 1496
Temp. Rise
51 50 49 49 48
Watts 377 433 489 546 602
(a)
Factory Setting.
Table 13. S9V2B080D4PSBC/D Heating Airflow
S9V2B080D4PSBC/D Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure
with Filter (iwc)
1st Stage Capacity = 50,300
2nd Stage Capacity = 77,350
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 864
CFM 808 795 782 770 757
Temp. Rise
58 59 60 61 62
Watts 82 126 171 216 261
Medium Low 907
CFM 836 823 810 797 784
Temp. Rise
56 57 58 59 60
Watts 94 137 180 223 266
Medium
(a)
958
CFM 896 881 866 851 836
Temp. Rise
51 53 54 56 57
Watts 110 153 196 238 281
High
1066
CFM 977 963 949 934 920
Temp. Rise
48 49 50 51 52
Watts 128 179 230 281 332
Heating 2nd
Stage
Low 1200
CFM 1125 1104 1082 1061 1039
Temp. Rise
64 65 67 68 69
Watts 191 241 292 342 392
Medium Low 1260
CFM 1188 1162 1135 1109 1082
Temp. Rise
61 62 64 65 66
Watts 219 273 326 380 434
Medium
(a)
1330
CFM 1243 1220 1197 1174 1151
Temp. Rise
58 59 60 61 62
Watts 259 309 360 410 461
High
1480
CFM 1342 1328 1313 1299 1284
Temp. Rise
53 54 55 56 56
Watts 329 389 448 508 567
(a)
Factory Setting.
HHeeaattiinngg aanndd CCoooolliinngg AAiirrffllooww TTaabblleess
