20
S9V2-VS-SVX001-1C-EN
Table 7. S9V2B060D3VSB Heating Airflow
S9V2B060D3VSB Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 710
CFM 636 649 662 675 688
Temp. Rise
55 53 52 51 50
Watts 49 86 124 161 199
Medium Low
(a)
810
CFM 732 740 748 756 764
Temp. Rise
47 47 47 46 46
Watts 65 105 146 186 226
Medium 890
CFM 817 820 823 826 828
Temp. Rise
42 42 42 42 42
Watts 82 123 164 206 247
High
1060
CFM 969 962 956 950 944
Temp. Rise
36 36 36 37 37
Watts 126 170 214 258 302
Heating 2nd
Stage
Low 900
CFM 836 840 844 848 852
Temp. Rise
64 64 63 63 62
Watts 79 126 173 219 266
Medium Low
(a)
1030
CFM 951 955 959 963 967
Temp. Rise
56 56 56 55 55
Watts 112 163 213 264 314
Medium 1130
CFM 1051 1052 1054 1055 1056
Temp. Rise
51 51 51 51 51
Watts 145 197 249 301 352
High
1350
CFM 1251 1238 1225 1212 1199
Temp. Rise
43 43 44 44 45
Watts 236 291 347 402 458
Table 8. S9V2B060U3VSB/S9V2B060D3VSB Cooling Airflow
S9V2B060U3VSB Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with Filter (iwc)
Outdoor
Tonnage -
"Odt" (tons)
Airflow
Setting -
(CFM/ton)
EXTERNAL STATIC PRESSURE (IN. W. C.)
0.1 0.3 0.5 0.7 0.9
1.5
450
CFM / WATTS 663 / 47 673 / 83 666 / 119 641 / 155 596 / 192
420
CFM / WATTS 621 / 41 630 / 75 621 / 109 595 / 144 549 / 180
400
CFM / WATTS 582 / 36 580 / 67 566 / 99 528 / 130 507 / 170
370
CFM / WATTS 549 / 32 556 / 63 546 / 95 517 / 128 469 / 162
350
CFM / WATTS 521 / 29 527 / 59 516 / 90 486 / 122 437 / 156
330
CFM / WATTS 492 / 26 497 / 55 486 / 85 455 / 117 405 / 150
310
CFM / WATTS 463 / 23 468 / 51 455 / 81 423 / 112 372 / 145
290
CFM / WATTS 435 / 21 438 / 48 424 / 77 391 / 107 339 / 141
2.0
450
CFM / WATTS 878 / 90 893 / 135 890 / 179 869 / 223 829 / 266
420
CFM / WATTS 821 / 76 834 / 119 830 / 161 808 / 202 767 / 244
400
CFM / WATTS 770 / 66 778 / 105 770 / 144 742 / 182 725 / 230
370
CFM / WATTS 725 / 57 737 / 96 731 / 134 707 / 172 664 / 211
350
CFM / WATTS 687 / 51 698 / 88 691 / 124 666 / 161 622 / 199
330
CFM / WATTS 649 / 45 659 / 80 651 / 115 625 / 151 580 / 188
310
CFM / WATTS 611 / 39 620 / 73 611 / 107 584 / 142 538 / 177
290
CFM / WATTS 573 / 34 581 / 67 571 / 99 543 / 133 496 / 168
2.5
450
CFM / WATTS 1097 / 159 1114 / 212 1114 / 265 1097 / 317 1061 / 368
420
CFM / WATTS 1023 / 133 1040 / 184 1039 / 233 1020 / 282 984 / 331
400
CFM / WATTS 976 / 117 989 / 166 990 / 214 970 / 261 932 / 308
370
CFM / WATTS 902 / 97 917 / 142 915 / 187 894 / 232 855 / 276
350
CFM / WATTS 854 / 84 868 / 128 865 / 171 843 / 214 803 / 257
330
CFM / WATTS 806 / 73 819 / 115 815 / 157 793 / 198 752 / 239
310
CFM / WATTS 759 / 63 771 / 103 766 / 143 742 / 182 700 / 222
290
CFM / WATTS 711 / 55 722 / 93 716 / 130 692 / 168 648 / 206
3.0
(a)
450
CFM / WATTS 1319 / 260 1340 / 321 1343 / 382 1328 / 441 1295 / 501
420
CFM / WATTS 1229 / 215 1249 / 274 1251 / 331 1235 / 387 1201 / 443
400
CFM / WATTS 1170 / 189 1189 / 245 1190 / 300 1173 / 354 1139 / 408
370
CFM / WATTS 1082 / 154 1100 / 206 1099 / 258 1081 / 309 1046 / 360
350
(a)
CFM / WATTS 1023 / 133 1040 / 184 1039 / 233 1020 / 282 984 / 331
330
CFM / WATTS 965 / 114 981 / 163 979 / 210 960 / 257 922 / 304
310
CFM / WATTS 907 / 98 922 / 144 919 / 189 899 / 234 860 / 278
290
CFM / WATTS 850 / 83 863 / 127 860 / 170 838 / 212 798 / 255
HHeeaattiinngg aanndd CCoooolliinngg AAiirrffllooww TTaabblleess
