S9V2-VS-SVX001-1C-EN
21
Table 9. S9V2B080U4VSB Heating Airflow
S9V2B080U4VSB Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 51,050
2nd Stage Capacity = 76,700
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 864
CFM 860 849 838 827 816
Temp. Rise
54 55 56 57 58
Watts 87 125 163 200 238
Medium Low
(a)
907
CFM 907 893 879 865 852
Temp. Rise
51 52 53 54 54
Watts 97 135 174 212 251
Medium 958
CFM 957 930 903 876 849
Temp. Rise
49 50 51 52 53
Watts 112 153 194 234 275
High
1051
CFM 1042 1015 989 962 936
Temp. Rise
45 46 47 47 48
Watts 140 182 225 267 310
Heating 2nd
Stage
Low 1200
CFM 1211 1206 1201 1197 1192
Temp. Rise
60 60 60 60 60
Watts 196 248 300 352 404
Medium Low
(a)
1260
CFM 1258 1261 1263 1265 1268
Temp. Rise
58 57 57 57 57
Watts 215 271 326 381 436
Medium 1330
CFM 1307 1303 1299 1296 1292
Temp. Rise
55 55 55 55 55
Watts 260 312 364 416 468
High
1460
CFM 1431 1412 1393 1374 1355
Temp. Rise
50 51 52 52 53
Watts 334 390 445 501 557
Table 10. S9V2B080D4VSB Heating Airflow
S9V2B080D4VSB Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 51,150
2nd Stage Capacity = 76,900
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 864
CFM 780 776 772 768 764
Temp. Rise
60 60 61 61 61
Watts 94 135 176 216 257
Medium Low 907
CFM 807 811 814 818 822
Temp. Rise
57 57 58 58 58
Watts 101 151 201 252 302
Medium
(a)
958
CFM 862 862 862 861 861
Temp. Rise
54 54 54 54 54
Watts 117 168 219 271 322
High
1066
CFM 977 963 949 934 920
Temp. Rise
48 49 50 51 52
Watts 128 179 230 281 332
Heating 2nd
Stage
Low 1200
CFM 1111 1104 1096 1088 1081
Temp. Rise
66 66 66 66 66
Watts 204 260 317 373 429
Medium Low 1260
CFM 1193 1201 1209 1217 1225
Temp. Rise
59 59 59 59 59
Watts 232 296 360 424 488
Medium
(a)
1330
CFM 1217 1217 1216 1215 1215
Temp. Rise
58 58 58 58 59
Watts 273 335 396 457 518
High
1480
CFM 1342 1328 1313 1299 1284
Temp. Rise
53 54 55 56 56
Watts 329 389 448 508 567
HHeeaattiinngg aanndd CCoooolliinngg AAiirrffllooww TTaabblleess
