Trane S9V2B040U3VSB User Manual

22
S9V2-VS-SVX001-1C-EN
Table 11. S9V2B080U4VSB / S9V2B080D4VSBD Cooling Airflow
S9V2B080U4VSB / S9V2B080D4VSB Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with
Filter (iwc)
Outdoor
Tonnage -
"Odt" (tons)
Airflow
Setting -
(CFM/ton)
EXTERNAL STATIC PRESSURE (IN. W. C.)
0.1 0.3 0.5 0.7 0.9
2.0
450
CFM / WATTS 892 / 91 899 / 136 893 / 180 872 / 222 838 / 265
420
CFM / WATTS 834 / 77 841 / 120 834 / 161 813 / 202 777 / 243
400
CFM / WATTS 785 / 67 785 / 106 781 / 146 754 / 183 737 / 229
370
CFM / WATTS 738 / 58 744 / 97 736 / 134 714 / 172 677 / 210
350
CFM / WATTS 700 / 52 705 / 89 697 / 125 675 / 161 638 / 198
330
CFM / WATTS 662 / 46 666 / 81 658 / 116 635 / 151 598 / 187
310
CFM / WATTS 624 / 40 627 / 74 619 / 107 596 / 142 558 / 177
290
CFM / WATTS 585 / 35 588 / 67 580 / 100 557 / 133 518 / 168
2.5
450
CFM / WATTS 1108 / 159 1120 / 213 1116 / 265 1098 / 315 1065 / 365
420
CFM / WATTS 1035 / 133 1046 / 184 1041 / 233 1022 / 281 989 / 328
400
CFM / WATTS 988 / 118 997 / 167 992 / 214 972 / 260 938 / 306
370
CFM / WATTS 916 / 97 924 / 143 918 / 188 897 / 231 863 / 275
350
CFM / WATTS 868 / 85 875 / 129 868 / 172 848 / 213 813 / 255
330
CFM / WATTS 820 / 74 826 / 116 819 / 157 798 / 197 762 / 237
310
CFM / WATTS 772 / 64 778 / 104 770 / 143 749 / 182 712 / 221
290
CFM / WATTS 724 / 56 729 / 94 721 / 131 699 / 168 663 / 205
3.0
450
CFM / WATTS 1326 / 257 1341 / 320 1341 / 380 1325 / 439 1296 / 497
420
CFM / WATTS 1239 / 214 1252 / 273 1250 / 330 1234 / 385 1203 / 440
400
CFM / WATTS 1181 / 188 1193 / 245 1191 / 299 1173 / 353 1142 / 405
370
CFM / WATTS 1094 / 153 1105 / 207 1101 / 258 1083 / 308 1050 / 358
350
CFM / WATTS 1036 / 133 1046 / 184 1041 / 233 1022 / 281 989 / 329
330
CFM / WATTS 978 / 115 987 / 164 982 / 210 962 / 256 928 / 302
310
CFM / WATTS 920 / 99 929 / 145 923 / 189 902 / 233 868 / 277
290
CFM / WATTS 863 / 84 870 / 128 863 / 170 843 / 212 807 / 253
4.0
(a)
450
CFM / WATTS 1769 / 570 1791 / 648 1797 / 725 1789 / 799 1766 / 873
420
CFM / WATTS 1650 / 469 1670 / 544 1675 / 616 1664 / 686 1639 / 756
400
CFM / WATTS 1571 / 410 1590 / 481 1593 / 550 1582 / 618 1555 / 685
370
CFM / WATTS 1453 / 330 1470 / 397 1472 / 462 1458 / 526 1430 / 588
350
(a)
CFM / WATTS 1375 / 284 1391 / 348 1391 / 410 1376 / 471 1347 / 530
330
CFM / WATTS 1297 / 242 1312 / 303 1311 / 363 1295 / 420 1265 / 477
310
CFM / WATTS 1219 / 205 1233 / 263 1230 / 319 1214 / 374 1183 / 428
290
CFM / WATTS 1142 / 172 1154 / 227 1151 / 280 1133 / 332 1101 / 384
Table 12. S9V2C100U4VSB Heating Airflow
S9V2C100U4VSAC/D Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure
with Filter (iwc)
1st Stage Capacity = 64,200
2nd Stage Capacity = 97,150
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 1146
CFM 1132 1120 1108 1097 1085
Temp. Rise
52 52 52 52 53
Watts 139 192 246 299 352
Medium Low 1280
CFM 1265 1251 1237 1223 1209
Temp. Rise
46 47 47 48 48
Watts 187 239 291 343 395
Medium 1359
CFM 1291 1269 1248 1226 1205
Temp. Rise
45 46 46 47 47
Watts 211 272 332 393 454
High
(a)
1446
CFM 1401 1404 1408 1412 1415
Temp. Rise
41 41 41 41 41
Watts 255 311 367 423 479
Heating 2nd
Stage
Low 1450
CFM 1421 1416 1412 1408 1404
Temp. Rise
63 63 63 63 63
Watts 272 336 401 466 531
Medium Low 1620
CFM 1620 1611 1602 1593 1584
Temp. Rise
55 55 55 56 56
Watts 354 424 493 562 631
Medium 1720
CFM 1646 1643 1640 1638 1635
Temp. Rise
53 54 54 54 54
Watts 408 484 559 635 711
High
(a)
1830
CFM 1805 1787 1768 1749 1731
Temp. Rise
49 50 50 51 51
Watts 525 579 633 687 741
HHeeaattiinngg aanndd CCoooolliinngg AAiirrffllooww TTaabblleess
