Table 13. S9V2C100D4VSB Heating Airflow
S9V2C100D4VSB Furnace Heating Airflow (CFM), Temp. Rise (°F), and Power (Watts) vs. External Static Pressure with
Filter (iwc)
1st Stage Capacity = 64,300
2nd Stage Capacity = 97,071
Heating
Airflow
Setting
Target
Airflow
External Static Pressure
0.1 0.3 0.5 0.7 0.9
Heating 1st
Stage
Low 1080
CFM 1068 1048 1029 1009 989
Temp. Rise
55 57 60 63 66
Watts 101 151 201 251 301
Medium Low 1166
CFM 1158 1113 1068 1023 978
Temp. Rise
51 53 55 57 59
Watts 115 172 229 285 342
Medium
(a)
1318
CFM 1326 1272 1218 1164 1111
Temp. Rise
46 48 50 51 53
Watts 153 206 259 312 365
High
1361
CFM 1312 1270 1229 1188 1147
Temp. Rise
46 47 47 48 49
Watts 166 221 276 331 387
Heating 2nd
Stage
Low 1500
CFM 1514 1478 1441 1404 1367
Temp. Rise
58 60 61 63 64
Watts 223 297 370 443 516
Medium Low 1620
CFM 1620 1588 1556 1523 1491
Temp. Rise
55 56 57 58 59
Watts 276 345 415 484 553
Medium
(a)
1830
CFM 1768 1746 1724 1702 1620
Temp. Rise
50 51 52 53 53
Watts 372 446 520 594 668
High
1890
CFM 1810 1783 1756 1729 1702
Temp. Rise
49 50 51 52 52
Watts 405 476 548 677 695
Table 14. S9V2C100U4VSB / S9V2C100D4VSB Cooling Airflow
S9V2C100U4VSB / S9V2C100D4VSB Furnace Cooling Airflow (CFM) and Power (Watts) vs. External Static Pressure with
Filter (iwc)
Outdoor
Tonnage -
"Odt" (tons)
Airflow
Setting -
(CFM/ton)
EXTERNAL STATIC PRESSURE (IN. W. C.)
0.1 0.3 0.5 0.7 0.9
2.5
450
CFM / WATTS 1153 / 111 1149 / 159 1147 / 208 1145 / 260 1141 / 314
420
CFM / WATTS 1077 / 94 1073 / 138 1071 / 185 1068 / 235 1064 / 287
400
CFM / WATTS 1061 / 90 1057 / 134 1054 / 180 1044 / 227 1021 / 273
370
CFM / WATTS 950 / 69 945 / 109 942 / 151 939 / 197 935 / 246
350
CFM / WATTS 899 / 60 893 / 98 890 / 140 887 / 184 882 / 232
330
CFM / WATTS 848 / 53 841 / 89 838 / 129 835 / 172 830 / 219
310
CFM / WATTS 796 / 46 789 / 80 786 / 119 782 / 161 777 / 208
290
CFM / WATTS 745 / 39 737 / 72 733 / 110 729 / 151 724 / 198
3.0
450
CFM / WATTS 1378 / 178 1376 / 234 1374 / 292 1372 / 352 1368 / 413
420
CFM / WATTS 1289 / 149 1286 / 201 1284 / 256 1282 / 312 1277 / 371
400
CFM / WATTS 1228 / 131 1225 / 181 1223 / 234 1221 / 288 1217 / 345
370
CFM / WATTS 1138 / 108 1134 / 154 1132 / 203 1130 / 255 1125 / 309
350
CFM / WATTS 1077 / 94 1073 / 138 1071 / 185 1068 / 235 1064 / 287
330
CFM / WATTS 1016 / 81 1011 / 123 1009 / 168 1006 / 216 1002 / 266
310
CFM / WATTS 955 / 70 950 / 110 947 / 153 944 / 199 940 / 248
290
CFM / WATTS 894 / 59 888 / 97 885 / 138 882 / 183 877 / 231
3.5
450
CFM / WATTS 1601 / 269 1599 / 334 1597 / 401 1594 / 469 1590 / 539
420
CFM / WATTS 1498 / 224 1496 / 284 1494 / 347 1491 / 411 1487 / 477
400
CFM / WATTS 1428 / 196 1426 / 254 1424 / 314 1422 / 376 1417 / 439
370
CFM / WATTS 1324 / 160 1321 / 214 1319 / 270 1317 / 327 1313 / 387
350
CFM / WATTS 1253 / 138 1251 / 190 1249 / 243 1246 / 298 1242 / 355
330
CFM / WATTS 1183 / 119 1180 / 167 1178 / 218 1175 / 271 1171 / 326
310
CFM / WATTS 1112 / 102 1109 / 147 1107 / 196 1104 / 246 1100 / 299
290
CFM / WATTS 1041 / 86 1037 / 129 1035 / 175 1032 / 223 1028 / 275
4.0
(a)
450
CFM / WATTS 1820 / 388 1819 / 462 1816 / 538 1812 / 615 1807 / 693
420
CFM / WATTS 1704 / 321 1702 / 390 1700 / 461 1697 / 533 1692 / 607
400
CFM / WATTS 1626 / 281 1624 / 347 1622 / 415 1619 / 484 1614 / 554
370
CFM / WATTS 1507 / 228 1505 / 289 1504 / 352 1501 / 417 1497 / 482
350
(a)
CFM / WATTS 1428 / 196 1426 / 254 1424 / 314 1422 / 376 1417 / 439
330
CFM / WATTS 1348 / 168 1346 / 223 1344 / 280 1342 / 338 1338 / 399
310
CFM / WATTS 1268 / 143 1266 / 195 1264 / 248 1261 / 304 1257 / 362
290
CFM / WATTS 1188 / 120 1185 / 169 1183 / 220 1180 / 273 1176 / 328
