Trane SPLIT AC User Manual

17 48626782 rev 2
Contents
2.4.2.10. Swing Control
Deflector rod
Figure - 17
Use swing to adjust air ow direction. The horizontal louver changes direction at dened angle
and auto swing. Vertical louver can only be adjusted manually. Move deector rod manually to
adjust air ow direction.
Adjust air ow direction properly otherwise it can cause discomfort or uneven room temperatures.
2.4.2.11. Power ON and OFF
Press ON/OFF button to switch ON/OFF the unit. When power is ON, the unit operate in TRANE mode
by default.
Remote back light will glow in red .
2.4.3. Replacement of Batteries
Do not use combination of old and new batteries. Life of battery is more than six months in
normal usage.
To prevent batteries from leakage of electrolyte and damaging controller, remove the batteries,
if not using for long duration.
Batteries are to be replaced when “Low Battery” error is shown on display.
•
•
•
To Replace Batteries,
• Slide back cover and remove old batteries.
• Use two new AAA alkaline batteries (Recommended: Duracell®
#
‘AAA’ batteries rated 1.5V)
• Battery Poles must align with installation position (Refer Figure - 18)
Risk of explosion if batteries are replaced by an incorrect type. Dispose of used batteries according to the
instructions provided on the batteries.
1 2 3
Figure - 18
1.
2.
1.
2.
•
# Registered trademark of Duracell, P&G Inc.# Registered trademark of Duracell, P&G Inc.

Trane SPLIT AC Specifications

General

Type	Split AC
Cooling Capacity	Varies by model (e.g., 1.5 Ton, 2 Ton, etc.)
Energy Efficiency Ratio (EER)	Varies by model (typically ranges from 8.5 to 12.5)
Power Supply	220-240V, 50Hz
Refrigerant	R-410A
Noise Level (Indoor Unit)	Approximately 19-45 dB(A)
Noise Level (Outdoor Unit)	Varies by model (e.g., 50-60 dB(A))
Air Flow (Indoor Unit)	Varies by model
Dimensions (Indoor Unit)	Varies by model
Dimensions (Outdoor Unit)	Varies by model
Weight (Indoor Unit)	Varies by model
Weight (Outdoor Unit)	Varies by model
