Contents
2.5. Stabilizer Detail
AC Tonnage Stabilizer KVA
1.0 3
1.5 4
2 5
3. Maintenance
3.1. Cleaning air lter
Clogged air lter decreases cooling eciency. Clean lter at interval of two weeks.
Disconnect power supply before cleaning indoor unit.
Support pole
1
Lift Front panel up to an angle, keeping it attached
until it makes a clicking sound.
Clean units with soft, dry or moist cloth with water
or cleanser.
Use support pole to hold the front panel at its place
after lifting it.
•
•
•
Filter Handle
2
Hold the air lter handle and lift slightly to release
it from holder, pull downwards to remove air lter
from indoor unit.
•
3
Clean air lter with a vacuum cleaner or water, dry
in cool place.
•
Air freshening filter
4
Remove air freshening lters from its supporting
frame. Clean air freshening lter monthly, and
replace at an interval of 4-5 months.
Install air freshening lter into its original
position.
•
•
5
Insert upper part of air lter and place lter into
position, make sure left and right edges align
correctly.
•

Trane SPLIT AC Specifications

General

Type	Split AC
Cooling Capacity	Varies by model (e.g., 1.5 Ton, 2 Ton, etc.)
Energy Efficiency Ratio (EER)	Varies by model (typically ranges from 8.5 to 12.5)
Power Supply	220-240V, 50Hz
Refrigerant	R-410A
Noise Level (Indoor Unit)	Approximately 19-45 dB(A)
Noise Level (Outdoor Unit)	Varies by model (e.g., 50-60 dB(A))
Air Flow (Indoor Unit)	Varies by model
Dimensions (Indoor Unit)	Varies by model
Dimensions (Outdoor Unit)	Varies by model
Weight (Indoor Unit)	Varies by model
Weight (Outdoor Unit)	Varies by model
