Low-Voltage Starter Types
Environmental specification
• Operating temperature: 32°F to 104°F (0°C to 40°C).
• Storage temperature: -4°F to 149°F (-20°C to 65°C).
• Humidity: 95 percent non-condensing.
• Maximum elevation: 3280 ft (1000 m) rated output current.
• Derate 4 percent/3280 ft over rated altitudes up to 9840 ft (3000 m).
Dimensions
Table 6 provides some basic reference dimensions and weights for the remote AFD. Always refer
and use theTrane submittals for actual dimensions.
Digital data display
The following points are digitally displayed at the chiller controller:
• Frequency command
• Input line voltage
• Load-side amps
Harmonics
The remote AFD is a standard six pulse design.Therefore the harmonic level is ~35 percent total
demand distortionTDD as measured at the AFD input. If lower levels of attenuation are required,
upstream filtering would be required.
Table 6. Remote AFD dimensions
Frame
460 Vac 575 Vac
Width (in.) Depth (in.) Height (in.) Weight (lb)Power (hp) Max. Amps Power (hp) Max. Amps
D3/D4 150–350 394 150–400 356 48 24 86 1220
E2 450–600 649 450 400 56 24 90 1635
N/A N/A 500–650 560 64 24 90 1680
F3 650–750 791 750–1050 840 127 24 90 2885
950–1050 1031 N/A N/A 127 24 90 3185
F4 1150–1350 1360 1150–1550 1258 150 24 90 3720
CTV-PRB004.book Page 30 Sunday, December 18, 2011 6:39 PM
