Medium-Voltage Starter Types (10,000–13,800 Volts)
Figure 34. Remote-mounted, across-the-line dimensions
Figure 35. Remote-mounted, 11-kV, across-the-line starter
1. Current-limiting power fuses
2. Isolation switch (provision for one
lock)
3. Control-power transformer
4. Vacuum contactors
95"
36"
60"
INCOMING
LINE
LOW-VOLTAGE
SECTION
MAIN BUS
1
2
3
4
