62 CTV-PRB004-EN
Starter Options
Bottom-entry line power
Figure 44, p. 63 shows the same concept as above; however, it uses what is called an auxiliary
section that allows the customer to bring wires in from the bottom to power the main bus.
Figure 43. Top-entry, multiple, across-the-line starter arrangement (2.3–6.6 kV)
incoming line power
pull box
main bus
X- Line starterX- Line starter
80"
30"
72"
12"
18"
CTV-PRB004.book Page 62 Sunday, December 18, 2011 6:39 PM
