14
Horizontal Right Configuration
Refrigerant
Connections
Horizontal Left
Condensate
Drains
Low Voltage
Connections
inside unit
Refrigerant
Connections
Horizontal Left Configuration
Low Voltage
Connections
inside unit
Horizontal Right
Condensate Drains
Airflow
Airflow
Control
Pocket
Inside unit
Control
Pocket
Inside unit
