Trane TAM7A0C36H31SB User Manual

6
Note: If the unit must be transported in a horizontal
position, it must be laid on its back (marked “REAR”
on carton).
Note: To reassemble cabinet, follow the steps in
reverse order. Ensure electrical connections are
secure and the plug clips are engaged.
4.1 Disassemble cabinet for installation in tight areas or as needed.
Section 4. Optional Cabinet Disassembly
STEP 1 - Remove all four front panels. See Section
2.2.
Blower Electrical
Connections

Trane TAM7A0C36H31SB Specifications

General

Brand	Trane
Model	TAM7A0C36H31SB
Category	Air Handlers
Language	English
