The following table shows the features accessed by the
devices menu:
Table 7. HMI devices menu features
Feature Function
Displays a control overview of the EXV(s) in
the system.
Displays a control overview of the fan banks
(optional) in the system.
Displays a control overview of pumps
(optional) in the system.
Displays a control overview of the condenser
valve (optional) in the system.
Table 7. HMI devices menu features (continued)
Feature Function
Displays a control overview of the
economizer valves (optional) in the system.
Displays a control overview of the hot gas
bypass (load-balancing valve - optional).
Displays (Optional) the master/slave
(Primary/Secondary) configuration and
status.
Operating Procedures
