Table 15. BMS BO Objects: Status, alarms, and faults (continued)
Tag Name Array
Object
Type
Instance
Metasys N2
Address
Modbus
Register
EIP Read Tag
Name
EIP Write Tag Name
DTC2 Fault: Super Heat Fault
DTCFaults BO 136 28 10030
DTCFaults[29] WR_DTCFaults[29]
DTC3 Fault: Inverter Temperature
DTCFaults BO 137 29 10033
DTCFaults[32] WR_DTCFaults[32]
DTC3 Fault: Discharge Temperature
DTCFaults BO 138 30 10034
DTCFaults[33] WR_DTCFaults[33]
DTC3 Fault: Suction Pressure DTCFaults BO 139 31 10035
DTCFaults[34] WR_DTCFaults[34]
DTC3 Fault: Discharge Pressure
DTCFaults BO 140 32 10036
DTCFaults[35] WR_DTCFaults[35]
DTC3 Fault: 3 Phase Over Current DTCFaults BO 141 33 10037
DTCFaults[36] WR_DTCFaults[36]
DTC3 Fault: Cavity Temperature
DTCFaults BO 142 34 10038
DTCFaults[37] WR_DTCFaults[37]
DTC3 Fault: Leaving Air / Water
DTCFaults BO 143 35 10039
DTCFaults[38] WR_DTCFaults[38]
DTC3 Fault: Total Compression Ratio Fault
DTCFaults BO 144 36 10040
DTCFaults[39] WR_DTCFaults[39]
DTC3 Fault: Generic Bearing Motor Compressor
DTCFaults BO 145 37 10041
DTCFaults[40] WR_DTCFaults[40]
DTC3 Fault: Sensor Fault DTCFaults BO 146 38 10042
DTCFaults[41] WR_DTCFaults[41]
DTC3 Fault: SCR Temperature
DTCFaults BO 147 39 10043
DTCFaults[42] WR_DTCFaults[42]
DTC3 Fault: Lockout Fault DTCFaults BO 148 40 10044
DTCFaults[43] WR_DTCFaults[43]
DTC3 Fault: Winding Temperature Fault
DTCFaults BO 149 41 10045
DTCFaults[44] WR_DTCFaults[44]
DTC3 Fault: Super Heat Fault
DTCFaults BO 150 42 10046
DTCFaults[45] WR_DTCFaults[45]
DTC4 Fault: Inverter Temperature
DTCFaults BO 151 43 10049
DTCFaults[48] WR_DTCFaults[48]
DTC4 Fault: Discharge Temperature
DTCFaults BO 152 44 10050
DTCFaults[49] WR_DTCFaults[49]
DTC4 Fault: Suction Pressure DTCFaults BO 153 45 10051
DTCFaults[50] WR_DTCFaults[50]
DTC4 Fault: Discharge Pressure
DTCFaults BO 154 46 10052
DTCFaults[51] WR_DTCFaults[51]
DTC4 Fault: 3 Phase Over Current DTCFaults BO 155 47 10053
DTCFaults[52] WR_DTCFaults[52]
DTC4 Fault: Cavity Temperature
DTCFaults BO 156 48 10054
DTCFaults[53] WR_DTCFaults[53]
DTC4 Fault: Leaving Air / Water
DTCFaults BO 157 49 10055
DTCFaults[54] WR_DTCFaults[54]
DTC4 Fault: Total Compression Ratio Fault
DTCFaults BO 158 50 10056
DTCFaults[55] WR_DTCFaults[55]
DTC4 Fault: Generic Bearing Motor Compressor
DTCFaults BO 159 51 10057
DTCFaults[56] WR_DTCFaults[56]
DTC4 Fault: Sensor Fault DTCFaults BO 160 52 10058
DTCFaults[57] WR_DTCFaults[57]
DTC4 Fault: SCR Temperature
DTCFaults BO 161 53 10059
DTCFaults[58] WR_DTCFaults[58]
DTC4 Fault: Lockout Fault DTCFaults BO 162 54 10060
DTCFaults[59] WR_DTCFaults[59]
DTC4 Fault: Winding Temperature Fault
DTCFaults BO 163 55 10061
DTCFaults[60] WR_DTCFaults[60]
DTC4 Fault: Super Heat Fault
DTCFaults BO 164 56 10062
DTCFaults[61] WR_DTCFaults[61]
DTC5 Fault: Inverter Temperature
DTCFaults BO 165 57 10065
DTCFaults[64] WR_DTCFaults[64]
DTC5 Fault: Discharge Temperature
DTCFaults BO 166 58 10066
DTCFaults[65] WR_DTCFaults[65]
DTC5 Fault: Suction Pressure DTCFaults BO 167 59 10067
DTCFaults[66] WR_DTCFaults[66]
DTC5 Fault: Discharge Pressure
DTCFaults BO 168 60 10068
DTCFaults[67] WR_DTCFaults[67]
DTC5 Fault: 3 Phase Over Current DTCFaults BO 169 61 10069
DTCFaults[68] WR_DTCFaults[68]
DTC5 Fault: Cavity Temperature
DTCFaults BO 170 62 10070
DTCFaults[69] WR_DTCFaults[69]
DTC5 Fault: Leaving Air / Water
DTCFaults BO 171 63 10071
DTCFaults[70] WR_DTCFaults[70]
DTC5 Fault: Total Compression Ratio Fault
DTCFaults BO 172 64 10072
DTCFaults[71] WR_DTCFaults[71]
DTC5 Fault: Generic Bearing Motor Compressor
DTCFaults BO 173 65 10073
DTCFaults[72] WR_DTCFaults[72]
