50
ARTC-SVX013A-EN
Table 15. BMS BO Objects: Status, alarms, and faults (continued)
Tag Name Array
Object
Type
Instance
Metasys N2
Address
Modbus
Register
EIP Read Tag
Name
EIP Write Tag Name
DTC5 Fault: Sensor Fault DTCFaults BO 174 66 10074
DTCFaults[73] WR_DTCFaults[73]
DTC5 Fault: SCR Temperature
DTCFaults BO 175 67 10075
DTCFaults[74] WR_DTCFaults[74]
DTC5 Fault: Lockout Fault DTCFaults BO 176 68 10076
DTCFaults[75] WR_DTCFaults[75]
DTC5 Fault: Winding Temperature Fault
DTCFaults BO 177 69 10077
DTCFaults[76] WR_DTCFaults[76]
DTC5 Fault: Super Heat Fault
DTCFaults BO 178 70 10078
DTCFaults[77] WR_DTCFaults[77]
DTC6 Fault: Inverter Temperature
DTCFaults BO 179 71 10081
DTCFaults[80] WR_DTCFaults[80]
DTC6 Fault: Discharge Temperature
DTCFaults BO 180 72 10082
DTCFaults[81] WR_DTCFaults[81]
DTC6 Fault: Suction Pressure DTCFaults BO 181 73 10083
DTCFaults[82] WR_DTCFaults[82]
DTC6 Fault: Discharge Pressure
DTCFaults BO 182 74 10084
DTCFaults[83] WR_DTCFaults[83]
DTC6 Fault: 3 Phase Over Current DTCFaults BO 183 75 10085
DTCFaults[84] WR_DTCFaults[84]
DTC6 Fault: Cavity Temperature
DTCFaults BO 184 76 10086
DTCFaults[85] WR_DTCFaults[85]
DTC6 Fault: Leaving Air / Water
DTCFaults BO 185 77 10087
DTCFaults[86] WR_DTCFaults[86]
DTC6 Fault: Total Compression Ratio Fault
DTCFaults BO 186 78 10088
DTCFaults[87] WR_DTCFaults[87]
DTC6 Fault: Generic Bearing Motor Compressor
DTCFaults BO 187 79 10089
DTCFaults[88] WR_DTCFaults[88]
DTC6 Fault: Sensor Fault DTCFaults BO 188 80 10090
DTCFaults[89] WR_DTCFaults[89]
DTC6 Fault: SCR Temperature
DTCFaults BO 189 81 10091
DTCFaults[90] WR_DTCFaults[90]
DTC6 Fault: Lockout Fault DTCFaults BO 190 82 10092
DTCFaults[91] WR_DTCFaults[91]
DTC6 Fault: Winding Temperature Fault
DTCFaults BO 191 83 10093
DTCFaults[92] WR_DTCFaults[92]
DTC6 Fault: Super Heat Fault
DTCFaults BO 192 84 10094
DTCFaults[93] WR_DTCFaults[93]
DTC1 Alarm: Inverter Temperature
DTCAlarms BO 193 85 10101
DTCAlarms[0] WR_DTCAlarms[0]
DTC1 Alarm: Discharge Temperature
DTCAlarms BO 194 86 10102
DTCAlarms[1] WR_DTCAlarms[1]
DTC1 Alarm: Suction Pressure DTCAlarms BO 195 87 10103
DTCAlarms[2] WR_DTCAlarms[2]
DTC1 Alarm: Discharge Pressure
DTCAlarms BO 196 88 10104
DTCAlarms[3] WR_DTCAlarms[3]
DTC1 Alarm: 3 Phase Current DTCAlarms BO 197 89 10105
DTCAlarms[4] WR_DTCAlarms[4]
DTC1 Alarm: Shaft / Cavity Temperature
DTCAlarms BO 198 90 10106
DTCAlarms[5] WR_DTCAlarms[5]
DTC1 Alarm: Leaving Water Temperature
DTCAlarms BO 199 91 10107
DTCAlarms[6] WR_DTCAlarms[6]
DTC1 Alarm: Total Compression Ratio
DTCAlarms BO 200 92 10108
DTCAlarms[7] WR_DTCAlarms[7]
DTC1 Alarm: SCR Temperature
DTCAlarms BO 201 93 10109
DTCAlarms[8] WR_DTCAlarms[8]
DTC1 Alarm: Super Heat Alarm
DTCAlarms BO 202 94 10114
DTCAlarms[13] WR_DTCAlarms[13]
DTC2 Alarm: Inverter Temperature
DTCAlarms BO 203 95 10117
DTCAlarms[16] WR_DTCAlarms[16]
DTC2 Alarm: Discharge Temperature
DTCAlarms BO 204 96 10118
DTCAlarms[17] WR_DTCAlarms[17]
DTC2 Alarm: Suction Pressure DTCAlarms BO 205 97 10119
DTCAlarms[18] WR_DTCAlarms[18]
DTC2 Alarm: Discharge Pressure
DTCAlarms BO 206 98 10120
DTCAlarms[19] WR_DTCAlarms[19]
DTC2 Alarm: 3 Phase Current DTCAlarms BO 207 99 10121
DTCAlarms[20] WR_DTCAlarms[20]
DTC2 Alarm: Shaft / Cavity Temperature
DTCAlarms BO 208 100 10122
DTCAlarms[21] WR_DTCAlarms[21]
DTC2 Alarm: Leaving Water Temperature
DTCAlarms BO 209 101 10123
DTCAlarms[22] WR_DTCAlarms[22]
DTC2 Alarm: Total Compression Ratio
DTCAlarms BO 210 102 10124
DTCAlarms[23] WR_DTCAlarms[23]
DTC2 Alarm: SCR Temperature
DTCAlarms BO 211 103 10125
DTCAlarms[24] WR_DTCAlarms[24]
DTC2 Alarm: Super Heat Alarm
DTCAlarms BO 212 104 10130
DTCAlarms[29] WR_DTCAlarms[29]
