824 Programmable Wi-Fi Comfort Control
18-HD72D1-6 3
SPECIFICATION DESCRIPTION
Product Model TCONT824
Product XL 824 Connected Control
Size 5-1/2” x 3-3/8” x 1” (WxHxD)
Configurations Heat Pump, Heat/Cool, Dual Fuel, Heat Only, Cooling Only
Maximum Number of Stages 5 Stages Heat, 2 Stages Cooling
Storage/Operating Temperature -40°F to 175°F, 5% to 95% RH non-condensing
Input Power 24VAC
Power Consumption 7VA*
Wire Usage 18 AWG
System Modes Auto, Heating, Cooling, Off, Emergency Heat
Fan Modes Auto, On, Circulate
Cooling Setpoint Temperature Range 60°F to 99°F, 1 °F resolution
Heating Setpoint Temperature Range 55°F to 90°F, 1 °F resolution
Indoor Temperature Display Range -40°F to 122°F
Outdoor Temperature Display Range -40°F to 140°F
Indoor Humidity Display Range 0% to 100%, 1% resolution
Minimum Cycle Off Time Delay Compressor: 5 minutes, Indoor Heat: 1 minute
*On every application, 24VAC loads should be reviewed to be sure the indoor unit control power transformer is adequately sized.
2. Product Specifications
3. General Information
3.1 Overview
The 824 Connected Control has a 4.3” color touch screen
and offers a full-featured and easy-to-use interface. From
individual daily schedules to remote access, the 824 is one
of the most advanced 24VAC Controls available.
3.2 Contents
— 1-Control
— 1-Sub-base
— 2-#6 18X1 Phillips slotted head mounting screws
— 2-#6x1 Nylon Drywall Anchors
— 1-Installation Guide
— 1-Quick Start Guide
— RJ-45 Holder and Screw
— 1-USB “On-the Go” Adapter Cable (Micro USB plug to
Standard USB receptacle)
3.3 Accessories
— Wired Remote Indoor Sensor (ZZSENSAL0400AA)
— Wired Remote Outdoor Sensor (BAYSEN01ATEMPA)
— Bonnet Thermostat model THT1248
(BAYSEN03ATEMPAA)
To Next Page
