824 Programmable Wi-Fi Comfort Control
18-HD72D1-6 39
8.5 System Report
The System Report Screen provides technicians with
important system operational data in one, concise screen.
The data is provided in real-time and updates as the data
changes.
The System Report Screen displays the following data
points:
— System Status - mode and stage of operation
— Load Value
— Fan Status
— Indoor Temperature
— Indoor Relative Humidity
— Heating and Cooling Setpoints
— Relative Humidity Setpoints
— Dehumidifier Status
— Outdoor Temperature
— Outdoor Relative Humidity (Nexia™ connection
required)
Currently Energized Terminals are displayed in green at the
bottom of the System Report screen.
8.6 Restore Factory Defaults
This feature will delete all saved settings, both user and
installer, and restore the 824 to its factory default settings.
This also includes any Wi-Fi and Z-Wave device settings.
