Trane Thermostats User Manual

BAS-SVX36C-EN 21
Installation
Figure 23. ProgrammableThermostat, 1H Only, Conventional Without Fan (Option 3)
24 Vac
C
G
Y
W
Rc
R
W2
Y2
A
S1
S2
Heat
L2
L1 (hot)
(jumper
installed)
Economizer/TOD
Remote Temperature Sensor
Figure 24. ProgrammableThermostat, 1H, Conventional With Fan (Option 4)
Fan
24 Vac
C
G
Y
W
Rc
R
W2
Y2
A
S1
S2
Heat
L2
L1 (hot)
(jumper
installed)
Economizer/TOD
Remote Temperature Sensor
Figure 25. ProgrammableThermostat, 1C, Conventional (Option 5)
Fan
24 Vac
C
G
Y
W
Rc
R
W2
Y2
A
S1
S2
Compressor
L2
L1 (hot)
(jumper
installed)
Economizer/TOD
Remote Temperature Sensor
