BAS-SVX36C-EN 39
Operation
Day-to-Day Operation
After a programmable thermostat is configured and the schedule is programmed, the thermostat
automatically changes the setpoints and fan settings according to the schedule.However, there are
some operator tasks that you may need or want to perform:
• Show setpoint or current temperature.You can temporarily or permanently switch the main
display
from current temperature to temperature setpoint. See “Showing the Setpoint or
Temperature on Display,” p. 39.
• Set the system mode, which includes turning the system on or off, and switching between
heating,
cooling, and automatic heating and cooling. See “Changing the System Mode,” p. 34.
• Override the schedule. If an unexpected, one-time temperature setpoint or fan mode change is
needed
you can temporarily override the schedule. See “Timed Override (TOV) Mode,” p. 40.
• Lock or unlock.You can lock the thermostat buttons to prevent changes to the thermostat
set
tings. See “Locking or Unlocking Modes,” p. 40.
Note: It
is possible for a programmable thermostat to be configured to be a non-programmable
thermostat. If installation configuration option #140 is set to 0, schedule programming
capabilities will be absent.
Showing the Setpoint or Temperature on Display
Depending upon the value of configuration option #210, the large numeric display could show any
of the following:
Figure 37. Display Options
To switch between the current temperature, “o dr” temperature, and the setpoint temperature,
press and hold the and buttons for 3 sec.The display will toggle as shown in Figure 37.
Value of configuration
option #210
Numeric display options
(press and for 3 sec to change)
0 The current local temperature, or the current or most recent temperature setpoint
1 or 2 The current local or remote indoor temperature or the current or most recent temperature
setpoint
3 The current indoor temperature, the current or most recent temperature setpoint, or the
current remote outdoor temperature, which only appears for 8 sec before reverting to
current indoor temperature or setpoint
.
.
Mo
AM
Current temperature Current (or most
recent) setpoint
Current outdoor
temperature
Arrow indicates
setpoint
“o dr” indicates outdoor
temperature (after 8 sec,
returns to previous mode)
