46 BAS-SVX36C-EN
Troubleshooting
Table 11. System Test Descriptions
Test Number
Description Values
1H/1C Thermostat
(p/n X13511535-01)
3H/2C Thermostat
(p/n X13511536-01)
Programmable
Thermostat
1
(1)
(1) Only values 0 and 1 are available because there are only one heat and one cool stage.
1 1 Heating system 0 = all heating stages off
1 = heat stage 1 on; heat stage 2 off
2 = heat stage 2 on; heat stage 1 off
3 = heat stage 1 and 2 on
This setting remains active when you scroll to the next setting.
2
(1)
2 2 Cooling system 0 = all cooling stages off
1 = cool stage 1 on; cool stage 2 off
2 = cool stage 2 on; cool stage 1 off
3 = cool stage 1 and 2 turn on
This setting remains active when you scroll to the next setting.
333 Fan system 0 = fan off
1 = fan on
This setting remains active when you scroll to the next setting.
NA 4 4 O/B changeover valve 0 = changeover valve off
1 = changeover valve on
This setting remains active when you scroll to the next setting.
NA NA 5 TOD/Economizer system 0 = TOD/Economizer off
1 = TOD/Economizer on
This setting remains active when you scroll to the next setting.
NA 5 NA Auxiliary Heat 0 = Auxiliary heat and fan turns off
1 = Auxiliary heat and fan turns off
This setting remains active when you scroll to the next setting.
NA 6 NA Emergency Heat 0 = Emergency relay, fan, and terminal L output turn off
1 = Emergency relay, fan, and terminal L output turn on
This setting remains active when you scroll to the next setting.
586 LCD segments 0 = full segment on
1 = odd segments on; even segments off
2 = even segments on; odd segments off
This setting is deactivated when you scroll to the next setting.
NA NA 7 Remote thermistor (S1 & S2)
temperature reading
0 = show temperature reading in Fahrenheit
1 = show temperature reading in Celsius
This setting is deactivated when you scroll to the next setting.
478 Internal thermistor
temperature reading
0 = show temperature reading in Fahrenheit
1 = show temperature reading in Celsius
This setting is deactivated when you scroll to the next setting for
the 3H/2C and programmable thermostats, but it remains active
when you scroll to the next setting for the 1H/1C thermostat.
699 Major software version Show major software revision number.
This setting is deactivated when you scroll to the next setting.
71010 Minor software version Show minor software version.
This setting is deactivated when you scroll to the next setting.
81111 Power up test 0 = do not run power up test on self-test exit
1 = run power up test on self-test exit
This setting retained (and applied) upon exit from self-test mode.
