BAS-SVX36C-EN 25
Installation
Applying Power
Applying power to the thermostat will initiate a power up sequence.
1. The full screen appears for 1.5 seconds.
2. The firmware version appears for 1.5 seconds:
• On
the programmable thermostat, the firmware version shows in the HH:MM digits.
• On the non-programmable thermostats, the digits are split between the top and bottom
regions of the screen: the most significant digits are at the top.
3. Power up tests are performed.
• If
an error is detected, an error code appears (see “Error Codes,” p. 43).
• If no errors are detected, the home screen appears (see Figure 33).
Figure 33. Home screens
.
.
Mo
AM
Programmable
thermostat
Non-programmable
thermostats
