Chiller Troubleshooting
ARTC-SVX002A-EN 69
5690 PU communication internal Internal communication error. Contact your local ABB representative.
5691 Measurement circuit ADC Measurement circuit fault. Contact your local ABB representative.
5692 PU board powerfail Power unit power supply failure. Contact your local ABB representative.
5693 Measurement circuit DFF Measurement circuit fault. Contact your local ABB representative.
5696 PU state feedback
State feedback from output phases does
not match control signals.
Contact your local ABB representative.
5697 Charging feedback Charging feedback signal missing.
Check the feedback signal coming from
the charging system
6181 FPGA version incompatible
Firmware and FPGA versions are
incompatible.
Reboot the control unit (using
parameter
96.08 Control board boot) or by cycling
power. If the problem persists, contact
your local ABB representative
6306 FBA A mapping file
Fieldbus adapter A mapping file read
error.
Contact your local ABB representative.
6481 Task overload Internal fault.
Reboot the control unit (using
parameter
96.08 Control board boot) or by cycling
power. If the problem persists, contact
your local ABB representative
6487 Stack overflow Internal fault.
Reboot the control unit (using
parameter
96.08 Control board boot) or by cycling
power. If the problem persists, contact
your local ABB representative
64A1 Internal file load File read error.
Reboot the control unit (using
parameter
96.08 Control board boot) or by cycling
power. If the problem persists, contact
your local ABB representative
64B2 User set fault
Loading of user parameter set failed
because
• requested set does not exist
• set is not compatible with control
program
• drive was switched off during loading.
Ensure that a valid user parameter set
exists. Reload if uncertain.
64E1 Kernel overload Operating system error.
Reboot the control unit (using
parameter
96.08 Control board boot) or by cycling
power. If the problem persists, contact
your local ABB representative
6581 Parameter system Parameter load or save failed.
Try forcing a save using parameter
96.07 Parameter save manually. Retry.
65A1 FBA A parameter conflict
The drive does not have a functionality
requested by PLC, or requested
functionality has not been activated.
Check PLC programming.
Check settings of parameter groups 50
Fieldbus adapter (FBA) and 51 FBA A
settings.
6681
EFB comm loss Programmable fault:
58.14 Communication loss action
Communication break in embedded
fieldbus (EFB) communication.
Check the status of the fieldbus master
(online/offline/error etc.).
Check cable connections to the
EIA-485/X5 terminals 29, 30 and 31 on
the control unit.
6682 EFB config file
Embedded fieldbus (EFB) configuration
file could not be read.
Contact your local ABB representative.
6683 EFB invalid parameterization
Embedded fieldbus (EFB) parameter
settings inconsistent or not compatible
with selected protocol.
Check the settings in parameter group
58 Embedded fieldbus.
6684 EFB load fault
Embedded fieldbus (EFB) protocol
firmware could not be loaded.
Contact your local ABB representative.
Version mismatch between EFB protocol
firm
ware and drive firmware.
6685 EFB fault 2
Fault reserved for the EFB protocol
application.
Check the documentation of the
protocol.
Code (hex) Fault / Aux. code Cause What to do
