CNT-SVX11A-EN 21
Configuration
Fan configuration Default Valid range
Fan operation in heating Continuous Continuous
1
Cycling with capacity
Fan operation in cooling Continuous Continuous (during occupied)
Cycling with capacity (unoccupied)
Number of fan speeds One 1
Configurable fan speed heating High Off, high, auto
Configurable fan speed cooling High Off, high, auto
Zone sensor fan switch Enable Disable or enable
Table 8: Fan configuration ranges
Setpoint Default Valid range
Occupied heating setpoint 71°F 40 to 115°F
Occupied cooling setpoint 74°F 40 to 115°F
Occupied standby heating setpoint 67°F 40 to 115°F
Occupied standby cooling setpoint 78°F 40 to 115°F
Unoccupied heating setpoint 60°F 40 to 115°F
Unoccupied cooling setpoint 85°F 40 to 115°F
Heating setpoint low limit
1
40°F 40 to 115°F
Cooling setpoint low limit
1
40°F 40 to 115°F
Heating setpoint high limit
1
105°F 40 to 115°F
Cooling setpoint high limit
1
110°F 40 to 115°F
Thumbwheel setpoint Enable Disable or enable
Economizer setpoint 50°F 40 to 100°F
Humidity setpoint 60% 0 to 100%
Table 9: Setpoint defaults
1. The heating and cooling setpoint high and low limits only apply to the occupied and occupied standby setpoints and are not applied to the
unoccupied setpoints.
Table 10: Discharge air limit ranges
Default Valid Range
Low Limit
1
45°F 30 to 50°F
1. The low limit is the temperature at which the controller shuts down the unit to prevent the coil from frosting.
1. Fan will cycle when unoccupied
