44 CNT-SVX11A-EN
Appendix - Binary
Configuration
Binary input Function Configuration Description
or output
BI 1 Low temp detection Normally closed Closed: BIP 1 is Normal (no diagnostic)
Open: BIP 1 is Active (diagnostic)
BI 2 Condensate overflow Normally closed Closed: BIP 2 is Normal (no diagnostic)
Open: BIP 2 is Active (diagnostic)
BI 3 Occupancy/Generic Normally closed Closed: BIP 3 is Normal (Occupied)
Open: BIP 3 is Active (Unoccupied)
1
Normally open Open: BIP 3 is Normal (Occupied)
Closed: BIP 3 is Active (Unoccupied)
1
BI 4 Fan status
2
Normally open When the controller commands the fan on and the binary input
remains open for one minute, BIP is normal (diagnostic).
When the controller commands the fan on and the binary input
closes, BIP is active (no diagnostic).
J1-1 Fan Normally open De-energized: Fan off
Energized: Fan on
J1-2 RV Normally open De-energized: Heat
Energized: Cool
J1-3 Electric Heat/ Normally open De-energized: Off
Reheat Energized: Electric Heat/Reheat active
TB4-1 and TB4-2 Generic binary output Normally open De-energized: Output off (de-energized)
Energized: Output on (energized)
1. The occupancy input applications vary for standalone and communicated instances. For more information, see Occupancy arbitration
tables in the Appendix.
2. The fan status device is normally closed during normal fan operation. When the fan is off either from a fan failure or the controller com-
manding the fan off, the binary input device opens.
Binary Configuration
Table 29: Binary configuration details
