Dimensions and Weights
UNT-SVX07J-EN 25
Table 7. Model E Horizontal recessed unit dimensions (inches)
Unit Size 200-300 400 600 800 1000-1200
No. Fans 1 1 2 2 3
No. Motors 1 1 1 1 2
A 35 13/16 40 13/16 50 5/16 58 13/16 77 13/16
B 21 5/16 26 5/16 35 13/16 44 5/16 63 5/16
C 22 13/16 27 13/16 37 5/16 45 13/16 64 13/16
D 19 3/8 24 3/8 33 7/8 42 3/8 61 3/8
E 18 1/8 23 1/8 32 5/8 41 1/8 60 1/8
F 32 7/16 37 7/16 46 15/16 55 7/16 74 7/16
G 34 5/16 39 5/16 48 13/16 57 5/16 76 5/16
H 19 3/4 23 3/4 31 3/4 39 3/4 59 3/4
Notes: Coil connections are always on the drain pan side and opposite the control box. Coil connections are 5/8-in. O.D. sweat. See the Coil Connections
section for locations. All duct collar dimensions are to the outside of the collar. See the Fresh Air Openings Locations section for dimensions.
