Dimensions and Weights
UNT-SVX07J-EN 37
Table 13. Model M Inverted vertical cabinet unit dimensions (in.) and weights (lb)
Unit Size 02–03 04 06 08 10–12
A 33 5/16 38 5/16 47 13/16 56 5/16 75 5/16
B 21 5/16 26 5/16 35 13/16 44 5/16 63 5/16
C 7 5/8 7 1/8 8 7/8 7 1/8 7 5/8
D 18 24 30 42 60
E 19 5/16 24 5/16 33 13/16 42 5/16 61 5/16
F 19 3/4 23 3/4 31 3/4 39 3/4 59 3/4
Operating Weight 97 125 155 164 218
Shipping Weight 84 112 139 148 200
Notes: Coil connections are always on the drain pan side and opposite the control box. Coil connections are 5/8-in. O.D. sweat. See the Coil Connections
section for locations. All duct collar dimensions are to the outside of the collar. See the Fresh Air Openings Locations section for dimensions.
