32 VAV-SVX01C-EN
UCM Programming and Operation
5. Rover/Comm4 will launch. Click to launch the Scan for Devices dialog box.
6. The user may search by the address of a single UCM or scan the range of UCM addresses
specified
Note: Address for VAV UCM's range from 65-127.
7. Select the desired device or range of devices and click the Scan button. You’ll be able to watch
as the applications scan for the selected data.
Note: The numbers selected for each device (65-127) can be referenced back to address
selection for the UCM(s). See Tab l e 6, p . 16 , Dip Switch settings.
Figure 18. Rover/Comm4 application with the Scan for Devices dialog box.
Figure 19. Scanning for Devices screen
