BAS-SVX04C-EN • Wireless Sensors 47
Specifications
The following table presents specifications for all models of the wireless sensor sets.
Sensor operating temperature 32 to 122ºF (0 to 50ºC)
Receiver operating temperature -40 to 158ºF (-40 to 70ºC)
Storage temperature -40 to 185ºF (-40 to 85°C)
Storage and operating humidity range 5% to 95%, non-condensing
Accuracy 0.5 °F over a range of 55 to 85°F (12.8 to 29.4°C)
Resolution 0.125ºF over a range of 60 to 80ºF
(15.56 to 26.67°C)
0.25ºF when outside this range
Setpoint functional range (WZS only) 45 to 95ºF (7.22 to 35ºC)
Setpoint functional range (WDS only) 50 to 89.6ºF (10 to 32ºC)
Setpoint thumb wheel markings (WZS only) 50 to 85ºF (stamped every 5ºF) and *, **
11 to 29ºC (stamped every 3ºC) and *, **
Receiver voltage 24 V nominal ac/dc ± 10%
Receiver power consumption <1 VA
Housing Polycarbonate/ABS blend, UV protected, UL 94-5VA
flammability rating, suitable for application in a
plenum
Mounting 3.24 in (8.26 cm) for 2 mounting screws (supplied)
Sensor battery (2) AA, 1.5 V, 2800 mAh, lithium, 5-year life, UL listed
Range
(a)
(a)Range values are estimated transmission distances for satisfactory operation. Actual distance is job specific and
must be determined during site evaluation.
Open range: 2,500 ft (762 m)
(packet error rate = 2%)
Usable: 200 ft (61 m)
Typical: 75 ft (23 m)
Output power 100 mW
Radio frequency 2.4 GHz (IEEE Std 802.15.4-2003 compliant)
(2405–2480 MHz, 5 MHz spacing)
Radio channels 16
Address range 000–999
Minimum time between transmissions 30 seconds
Maximum time between transmissions 15 minutes
