Page #10 background imageLoading...
Page #10 background image
Wall of home
Patio Edge
Deck Edge
2’ Maximum overhang
from side of unit to
edge of deck
2’ Maximum overhang
from side of unit to
edge of deck
3’ Minimum Clearance
from side of unit to
wall of structure
Outdoor Unit
Outdoor wall
of home
Deck Edge
TOP VIEW
ISOMETRIC VIEW
Pg. 10
Illustrations provided to designate required clearances. Trane recommendeds mounting the unit on a pad
that is independent of the structure. Reference section III.A.1.F on Pg 8 of this document.
