Trane XL824 - Temperature Control Panel Usage; Manual Temperature Adjustment; Schedule Hold Management; Accessing Schedule Details

032-5090-06C-EN page 7
The Temperature Control Panel is where target
temperatures are manually set and adjusted.
The panel is shown on the Classic View Home
Screen only.
Temperature Control Panel
Hold
Until
Show
Schedule
Hold
Perm
82º
62º
Away
$
Home
Sleep
Increase
the
set point
Decrease
the
set point
Cooling Set Point
(select to change)
Available when
Scheduling is Enabled
Available when
Scheduling is Disabled
Activate 1-Touch Presets
Heating Set
Point (select to change)
Schedule Status Area
Mode
Indicator
OR
Disable Schedule
and maintain
current
temperature
settings.
Temporarily
overrides
Schedule
View and edit
Schedule
Select Heating and Cooling Set-points to
show panel.
