XT500C DELUXE PROGRAMMABLE HEAT-PUMP THERMOSTAT
7
69-1404
Pub. No. 18-HD25D2-2
(continued)
Table 3. Installer Setup Options for the XT500C
(Continued)
.
Press Time
▲ or ▼
Press Increase ▲ or Decrease ▼ to change setting
Installer
Factory Setting Other Choices
Actual
Select
Setup Number
Display Description Display Description
Setting
Minimum
Deadband
Between Heating
and Cooling in
Auto Changeover
Mode
30 4 Heating and cooling
setpoints can be set no
closer than 4°F (2°C)
3 thru 10 Heating and cooling
setpoints can be set
no closer than the
chosen value:
3—3°F (1.5°C)
4—4°F (2°C)
5—5°F (2.5°C)
6—6°F (3°C)
7—7°F (3.5°C)
8—8°F (4°C)
9—9°F (4.5°C)
10—10°F (5°C)
Minimum On Time
(Heat)
32 10 10-minute minimum on
time for compressor
0 thru 15 Minimum number of
minutes (0 thru 15) the
compressor will be on
during call for heat
Minimum On Time
(Cool)
33 10 10-minute minimum on
time for compressor
0 thru 15 Minimum number of
minutes (0 thru 15) the
compressor will be on
during call for cool
Temperature
range stops in
heating
34 85 Highest setpoint heating
can be set to
55 to 85 Temperature range
(1°F increments)
heating setpoint can
be set to
Temperature
range stops in
cooling
35 65 Lowest setpoint cooling
can be set to
65 to 99 Temperature range
(1°F increments)
cooling setpoint can
be set to
Temperature
display
adjustment
37 0 No difference in
displayed temperature
and actual room
temperature
3, 2, 1, -1,
-2, or
-3
3—Display adjusts to
3°F higher than actual
room temperature
2—Display adjusts to
2°F higher than actual
room temperature
1—Display adjusts to
1°F higher than actual
room temperature
-1—Display adjusts to
1°F lower than actual
room temperature
-2—Display adjusts to
2°F lower than actual
room temperature
-3—Display adjusts to
3°F lower than actual
room temperature
Minimum Off Time
(Heat)
38 5 5 minute minimum off
time for the compressor
0 thru 15 Minimum number of
minutes (0 thru 15) the
compressor will be off
between calls for heat
