Trane Zone Panel User Manual

2 18-HD66D1-4
2.1 Overview
2.2 Contents in Zone Panel Kit (ZZONEPNLAC52ZB)
2.3 Optional Accessories
2.4 Specifications
Specification Description
Product Model: ZZONEEXPAC52ZB
Product: Zone Panel
Size: 8.0” width x 9.3” height x 1.9” depth
Storage Temperature: -40° to 175°F, 5% to 95% RH non-condensing
Operating Temperature: -40° to 150°F, 5% to 95% RH non-condensing
Input Power: 24 VAC from external transformer (Range: 18-32 VAC)
Power Consumption: 2 VA for each Zone Panel (damper VA not included)
Wire usage: Minimum 18 gauge NEC approved control wiring
HVAC System Type Compatible: Standard (gas/oil/electric/hydronic), Heat Pump, Dual Fuel
Multistage System Compatible: Standard HVAC Systems: Up to 3 stages of heating and 2 stages of cooling (including
modulating heating)
Heat Pump Systems: Up to 5 stages of heating (2 compressor, 3 aux heat—including
modulating heating) and 2 stages of cooling
Communications: ~12 VDC
Product Model Description
*ZONE940AC52ZA Communicating Zone Sensor with Display
ZZSENSAL0400AA Non-Communicating Zone Sensor
SEN 00462 Return Air/Mixed Air Sensor
ZZONEEXPAC52ZB Additional Zone Panel for zones 5-8
120/240VAC Transformer Field-Supplied, sizing dependent on VA requirements of Zone Panel and installed components
The Zone Panel is a wall mounted low voltage panel that enables the control to connect to and manage
zoning components.
Open and inspect contents for damaged or missing
items. Each kit will contain:
Item Qty Description
1 1 Zone Panel cover
2 1 Zone Panel base
3 1 Discharge Air Temperature Sensor
4 1 Static Pressure Transducer
5 1 Transducer Enclosure
6 2 Static Pressure Probe
7 1 Clear Flexible Tubing (8 ft.)
8 4 Mounting screws/anchors
9 4 Wire Ties
10 4 Tubing Clamps
11 3 Clamp-style Connectors
12 1 Installer’s Guide (not pictured)
Section 2. General Information
1
2
4
3
5
10
11
6
8
9
7
ZONES
1 - 4
5 - 8
ByPass
Zone Dampers
Sensors
C
ommon
PO/Open
PC/Clos
e
Static Press
Gnd/Grn
S
ignal/Blk
+5
V/Red
Temper
atureRemote Indoor
Disch
ar
ge Air
Dischar
ge Air
Return A
i
r
R
e
tu
rn
Air
Mix
ed
Air
Mixed Air
Zo
ne 1
or 5
Zone
1 or 5
Zone 2
or 6
Zon
e
2
o
r 6
Zone
3 or 7
Z
one
3 or 7
Z
one
4
or 8
Zone 4 or 8
Zone
1 or 5
Ind
oor/
Relay P
anel
Ou
tdoor
Zone Panel
(Zones 5-8)
24V
Tran
s
.
Co
mmon
PO/Open
PC/Clo
s
e
Zone
2 or 6
C
ommon
PO/
Ope
n
PC/Clo
s
e
Zone
3 or 7
Common
PO/Ope
n
PC/Close
Zone
4 or 8
Common
PO/Ope
n
PC/
Close
Comm
R
BD B
B
R
BD
D
Zone Panel
