Trane Zone Panel - Page 27

27
TABLE 4
Static Pressure Sensors
Pressure (In WC)
Volts (DC)
Measured G to Blk
0.08 0.4
0.11 0.45
0.16 0.55
0.21 0.65
0.27 0.75
0.32 0.85
0.37 0.95
0.43 1.05
0.48 1.15
0.53 1.25
0.59 1.35
0.64 1.45
0.69 1.55
0.75 1.65
0.80 1.75
0.85 1.85
0.91 1.95
0.96 2.05
1.01 2.15
1.07 2.25
1.12 2.35
1.17 2.45
1.25 2.6
TABLE 5
Discharge/Mixed Air Temperature Sensors
TEMP
(deg. F)
TEMP
(deg. C)
Sensor Resistance
(Ohms)
Volts
(DC)
200 93.4 829 0.41
195 90.8 895 0.44
190 87.8 982 0.48
185 85.1 1070 0.52
180 82.2 1170 0.56
175 79.7 1272 0.60
170 76.8 1397 0.65
165 73.9 1536 0.71
160 71.3 1678 0.76
155 68.5 1847 0.83
150 65.7 2033 0.90
145 62.8 2250 0.97
140 60.0 2489 1.05
135 57.3 2750 1.14
130 54.5 3037 1.23
125 51.8 3368 1.33
120 49.0 3749 1.44
115 46.2 4169 1.55
110 43.4 4654 1.67
105 40.6 5193 1.79
100 37.8 5819 1.92
95 35.0 6523 2.06
90 32.3 7322 2.20
85 29.5 8233 2.35
80 26.7 9282 2.50
75 23.9 10501 2.65
70 21.2 11849 2.80
65 18.4 13442 2.95
60 15.6 15294 3.11
55 12.8 17408 3.26
50 10.1 19842 3.40
45 7.2 22764 3.55
40 4.4 26104 3.69
35 1.7 29936 3.81
30 -1.1 34520 3.94
25 -3.9 39869 4.05
20 -6.6 46134 4.16
TABLE 6
Non-Communicating & Return Air Sensors
TEMP
(deg. F)
TEMP
(deg. C)
Sensor Resistance
(Ohms)
Volts
(DC)
100 37.8 5815 2.07
95 35.0 6527 2.21
90 32.2 7331 2.35
85 29.5 8248 2.50
80 26.7 9279 2.65
75 23.9 10497 2.80
70 21.1 11868 2.95
65 18.4 13455 3.10
60 15.6 15276 3.25
55 12.8 17430 3.39
50 10.1 19851 3.53
45 7.3 22710 3.67
40 4.5 26051 3.80
35 1.7 29994 3.92
30 -1.0 34446 4.03
25 -3.9 39909 4.14
20 -6.6 46134 4.24
