6. CONNECTOR WIRING INFORMATION

DB9 connector for excitation output, signal input, and TEDS interface

Type B USB connector

Detachable screw-clamp plug for

digital control inputs A & B:

External B

Ground

External A

Detachable screw-clamp plug for

dual relay outputs 1 & 2:

Normally Open 2

Common

Normally Open 1
