4. RECEIVING & UNPACKING
Your SSI was carefully tested and inspected prior to shipment. Should your unit be
damaged in shipment, keep the shipping materials and notify the freight carrier immediately.
Verify that your SSI shipment includes the following items:
1. SSI Smart Sensor Indicator
2. SSI-USB/ACA AC adapter / battery charging unit with removable A-B USB cable.
3. SSI-SCC (2 ea.) Detachable 3-pin screw-clamp connectors for relay outputs and
external controls.
4. SSI Operator Manual (USB)
User manual. Also download from www.transducertechniques.com
Your shipment should also include the following accessories or options if ordered:
1. SSI-DLS Data Logging Software
2. SSI-TRES TEDS Reader Editor Software
3. SSI-AMB Adjustable Mounting Bracket
In the event that your unit is undamaged but is inoperable, return it to your place of
purchase for warranty repair or replacement. Please include a detailed description of the
problem. See the warranty instructions at the back of this manual.
Six mounting holes in the
top plate of the mounting
bracket allow meter attach-
ment in two orientations.
The base of the meter has
three inserts with 8-32 UNC
threads, 3/8” deep, for
attachment to the mounting
bracket. The inserts are in
a triangle pattern with a
1.500” base and 1.750”
height.
SSI-USB/ACA
AC adapter with removable
A-B USB cable
SSI-AMB Adjustable mounting bracket
