Transport and installation
Final installation on-site
45
Installation
In the case of long conveyors consisting of several sections, it may be advis-
able to fit supports to the individual sections before assembling the frame.
Depending on the design version, the supports are either equipped with
stand pipes or support angles. Installation is carried out in accordance with
the support layout drawing. The supports must always stand vertically; this
also applies to tracks with an incline.
Mount supports
Risk of fatal injury through crushing to parts of the body!
Machine can tilt and crush body parts.
Secure the machine to prevent it from falling.
Use hoists to raise and lower the machine.
Risk of fatal injury due to crushing to parts of the body!
Machine falls down.
Only use supports/suspensions approved by Transnorm.
Mount supports/suspensions exactly as described in the system layout
or support layout drawing, if available.
Do not exceed minimum spaces as defined in the system layout/support
layout drawing.
Complete the following steps:
1. Attach the supports or suspensions to the framework of the base frame
using the joining elements (1) provided.
2. Release the fixing screws (2) and adjust the angle of inclination.
