Trek 2021 E-CALIBER - Safety

2021 E-Caliber Service Manual
1
Contents
Safety 1
Headset with Knock Block 2
Frame and drive system guards 3
Rear triangle and chainstay bridge 4
Main pivot 6
Dérailleur hanger 7
Cabling overview 8
IsoStrut remote lockout cable 9
IsoStrut 10
Air volume spacer 11
Carriage wiper seals and bushings 14
Fazua system 19
Specications 20
Suspension 21
Safety
WARNING
Alwaystightenhardwaretothespeciedtorque.
Over-tightening hardware could deform or break the
hardwareorcomponents.Under-tighteninghardware
couldcausehardwareorcomponentstobecomeloose.
Either situation could damage the bicycle and result in
injurytotherider.
WARNING
All reused-fasteners with a pre-applied threadlocker
must be cleaned with isopropyl alcohol and have new
threadlockerappliedbeforere-assembly.Ifathreadlock-
er is not applied, the fasteners may loosen, which could
damagethebicycleandresultininjurytotherider.
